LG BP540 User Manual

Connecting 15
Connecting
2
Connecting to an amplifier via
HDMI output
Connect the player’s HDMI OUT jack to the
corresponding in jack on your amplier using a
HDMI cable.
HDMI cable
HDMI cable
TV
Receiver/Amplier
Rear of the unit
Connect the amplier’s HDMI output jack to HDMI
input jack on your TV using a HDMI cable if your
amplier has HDMI output jack (Refer to amplier’s
owner’s manual).
You will need to activate the player’s digital output.
(See “[AUDIO] Menu” on page 26.)
Connecting to an amplifier via
digital audio output
Connect the player’s COAXIAL OUT jack to the
corresponding in jack on your amplier using an
optional digital audio cable.
Coaxial
cable
Receiver/Amplier
Rear of the unit
You will need to activate the player’s digital output.
(See “[AUDIO] Menu” on page 26.)

LG BP540 Specifications

General

3D	Yes
Depth	200 mm
Width	360 mm
Height	40 mm
Weight	1360 g
Full HD	No
Device type	Blu-Ray player
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS, DTS 2.0, DTS-HD Master Audio
Package weight	1950 g
Disc types supported	BD, DVD
Card reader integrated	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio formats supported	AAC, FLAC, LPCM, MP3, WMA
Video formats supported	3GP, AVC, AVCHD, DAT, FLV, H.264, M4V, MKV, MOV, MP4, MPEG1, MPEG2, MPEG4, TS, VC-1, VOB, WMV
Power consumption (standby)	0.5 W
Power consumption (typical)	12 W
Audio output channels	- channels
