Appendix 67
Appendix
6
Specifications
General
Power requirements Refer to main label on the rear panel.
Power consumption 12 W
Dimensions (W x H x D) Approx. 360 mm x 41.5 mm x 200 mm (14.1” x 1.6” x 7.9”)
Net Weight (Approx.) 1.4 kg (3.0 lbs)
Operating temperature 5 °C - 35 °C (41 °F - 95 °F)
Operating humidity 5 % - 90 %
Outputs
HDMI OUT (video/audio) 19 pin (Type A, HDMI™ Connector)
DIGITAL AUDIO OUT (COAXIAL) 0.5 V (p-p), 75 Ω, RCA jack x 1
System
Laser Semiconductor laser
wavelength 405 nm / 650 nm
Signal system Standard NTSC color TV system
LAN port Ethernet jack x 1, 10BASE-T / 100BASE-TX
Wireless LAN (internal antenna) IEEE 802.11b/g/n (2.4 GHz band)
Bus Power Supply (USB) 5 V
0
500 mA
y
Design and specications are subject to change without notice.
