LG CJS98F User Manual

2-9
DISASSEMBLY INSTRUCTIONS
Figure 1
Figure 2
1. Case Top
1-1) Remove the 7 Screws.
1-2) Remove the Case Top.
2. Panel Front Assembly
2-1) Disconnect the 4 FFC Cables from the Main Board.
2-2) Unhook the 10 Locking Tabs by using Flat-head screwdriver.
2-3) Remove the Panel Front Assembly.
