Appendix22
Appendix
5
Specifications
General
Power supply Refer to the main label.
Power consumption Refer to the main label.
Net Weight 1.4 kg
External dimensions (W x H x D) 160 mm x 107 mm x 250 mm
Operating conditions Temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 85 %
Bus Power Supply DC 5 V
0
500 mA
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
Amplier
Output Power 20 W + 20 W
CD
Frequency Response 40 Hz to 20 kHz
Signal-to-noise ratio 70 dB
Dynamic range 55 dB
Speakers
Type 1 Way 1 Speaker
Impedance 6 Ω
Rated Input Power 20 W
Max. Input Power 40 W
Net Dimensions (WxHxD) 136 mm x 180 mm x 210 mm
Net Weight (1EA) 1.3 kg
• Design and specications are subject to change without notice.
