NSTALLATION INSTRUCTIONS
I
Step 3 :
PREPARING THE DISHWASHER
FOR INSTALLATION
1
Lay the dishwasher on its back.
2
Adjust the legs to the required height
as shown in below figure.
3
To reduce noise attach the strip to the
machine base.
Step 4 :
INSTALLING THE
DISHWASHER IN CUPBOARD
1
Before sliding the dishwasher into the
cupboard opening, all necessary height
and balancing adjustments should be
made using a spanner.
2
Slide the dishwasher into the cabinet,
opening carefully. Make sure that the
drain hose inside the cabinet is not
kinked or stretched.
Adjust
leg
6
If the height of the cupboard is below
850mm, you should remove the top
table by unscrewing the 2 screws.
(Two from rear)
CAUTION
Remove the adhesive
cover and attach the strip
to the machine base,
hiding the legs.
Trim the edges if desired.
The bottom of the strip
should touch the floor.
To Next Page
