LG E1942C User Manual

TROUBLESHOOTING
Do you see a "OSD LOCKED" message on the screen?
Do you see “OSD LOCKED” when
you push MENU button?

You can secure the current control settings, so that they cannot be
inadvertently changed. You can unlock the OSD controls at any time
by pushing the MENU button for several seconds: the message “OSD
UNLOCKED” will appear.
Display image is incorrect
Display Position is incorrect.

Press the AUTO button to automatically adjust your display image to
the ideal setting.
On the screen background, vertical
bars or stripes are visible.

Press the AUTO button to automatically adjust your display image to
the ideal setting.
Any horizontal noise appearing in
any image or characters are not
clearly portrayed.

Press the AUTO button to automatically adjust your display image to
the ideal setting.

Check Control Panel ► Display ► Settings and adjust the display
to the recommended resolution or adjust the display image to the ideal
setting. Set the color setting higher than 24 bits (true color).
19
ENG
ENGLISH
TROUBLESHOOTING
Check the following before calling for service.
No image appears
Is the power cord of the display

Check and see if the power cord is connected properly to the power
connected?
outlet.
Is the power indicator light on?

Press the Power button.
Is the power on and the power

indicator Red?
Is the power indicator flickering?

If the display is in power saving mode, try moving the mouse or
pressing any key on the keyboard to bring up the screen.

Try to turn on the PC.
Do you see an "OUT OF RANGE"

This message appears when the signal from the PC (video card) is
message on the screen?
out of horizontal or vertical frequency range of the display. See the
'Specifications' section of this manual and configure your display
again.
Do you see a "CHECK SIGNAL

This message appears when the signal cable between your PC and
CABLE" message on the screen?
your display is not connected. Check the signal cable and try again.
Adjust the brightness and the contrast.

LG E1942C Specifications

General

3D	No
HD type	-
Aspect ratio	16:9
Display diagonal	18.5 \
Display resolution	1366 x 768 pixels
Vertical scan range	56 - 75 Hz
Horizontal scan range	30 - 61 kHz
Viewing angle, vertical	65 °
Contrast ratio (dynamic)	5000000:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	90 °
Display brightness (typical)	200 cd/m²
Supported graphics resolutions	1366 x 768
DVI-D ports quantity	0
Certification	FCC-B CE
Product color	Black
Tilt angle range	-5 - 20 °
Panel mounting interface	75 x 75 mm
AC input voltage	100 - 240 V
Power consumption (standby)	0.3 W
Power consumption (typical)	15 W
Package depth	339 mm
Package width	505 mm
Package height	115 mm
Package weight	3200 g
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (with stand)	168 mm
Height (with stand)	349 mm
Weight (with stand)	2100 g
Depth (without stand)	55 mm
Width (without stand)	441 mm
Height (without stand)	275 mm
Weight (without stand)	1900 g
