3-27
6. USB
7. CRYSTAL
Figure 6-1.
USB D+/D-
IC500 Pin116, 117
Figure 7-1.
12 MHZ CRYSTAL
IC101 Pin9,10 / IC500 Pin111,112
D+
D-
XI
XO
