3-55 3-56
Part Name Location Division Spec(V) Real Voltage(V)
MAIN
LC87F5NC8A IC101 Vdd 2.8~5.5 3.49
M24C16
IC102 VCC 1.8~5.5 3.49
IC501 VCC 1.8~5.5 3.49
AZ7027RTRE1 IC100, IC103 VCC Max 18 3.48
CP2.0B IC254 Vcc 2.8~3.6 3.32
DRV603 IC251 Pvdd 3~5.5 3.32
CS5346_ADC IC200
VA 4.75~5.25 4.99
VD 3.13~3.47 3.32
VLS 3.13~5.25 3.32
VLC 3.13~5.25 3.32
MLC9800A IC500
AVDD33,
IOVDD33,
USBVDD33
3.1~3.6 3.32
PLLVDD12,
VDD12
1.1~1.3 1.197
MX25L8006EM2I-
12G
IC502 VDD 3.0~3.6 3.32
EM638165TSA-6G IC503 VCC 2.7~3.6 3.32
S3053 IC400 VCC1,2 4.3~13.2 4.99
LM37102D IC003
Vin 2.25~16 6.4
Vout 1.8~15 4.99
AZ1117BH IC001
Vin 12 12
Vout 1.5~10 7
S8082 IC402
PVCC 4.3~13.2 7
SVCC 4.3~13.2 7
TJ3965D IC004
Vin 3.5~15 3.713
Vout 3.22~3.38 3.32
AMP
PS9851 IC701
VDD_IO 2.97~3.63 3.31
VDD_IN1,2 2.2~3.3 3.31
VDD_OUT,
VDD_core
1.08~1.32 1.25
TAS5612PHD IC702
VDD 10.8~13.2 12.01
GVDD 10.8~13.2 12.01
PVDD 16~34.1 25.5
MC4580 IC700
VCC+ -18~+18 12.01
VCC- -18~+18 12.01
FRONT
MC3501 IC301 VDD 2.7~5.5 3.47
CY8C21434 IC302 VDD 1.71~5.5 3.47
I/O LM37102D-ADJ IC350
Vin 2.25~16 6.4
Vout 1.8~15 5.1
IPOD LM29152D-ADJ IC3P1
Vin 2.25~16 6.4
Vout 1.8~15 5.04
Part Location Value + -
MAIN
C011 100uF/16V 3.33 0
C016 47uF/50V 1.2 0
C104 1000uF/6V 3.478 0
C108 10uF/16V 11.61 0
C125 220uF/16V 12.1 0
C127 100uF/16V 3.474 0
C401 220uF/10V 4.99 0
C405 47uF/16V 3.326 0
C410 100uF/16V 1.659 0
C430 100uF/16V 1.832 0
FRONT
C301 47uF/50V 0 -26.98
C307 100uF/16V 3.466 -
C308 47uF/50V 0 -23.44
C316 100uF/16V 3.368 0
JACK C355 100uF/16V 5.08 0
IPOD C3P4 100uF/16V 5.02 0
AMP
C702 10uF/16V 12.01 0
C707 100uF/16V 1.245 0
C713 10uF/16V 6.01 0
C743 100uF/16V 2.377 0
C751 10uF/16V 12 0
C754 10uF/16V 12 0
C769 470/50V 25.5 0
C770 470/50V 25.5 0
CIRCUIT VOLTAGE CHART
1. ICs 2. CAPACITORS
