LG FLATRON E2040S - TROUBLESHOOTING: NO POWER; POWER INDICATOR OFF DIAGNOSTICS; VOLTAGE AND OSCILLATOR CHECKS


Copyright © 2010 LG Electronics. Inc. All right reserved. - 18 - LGE Internal Use Only
Only for training and service purposes
TROUBLESHOOTING GUIDE
No Power
(Power Indicator Off)
Please reinsert and
make sure the AC of
100-240V is normal
Measure
U701 PIN2=3.3V

Check the Adapter/Inverter
section
Check CN702 or replace
U701
NO
NO
YES
YES
1. NO POWER
Check X401 oscillate
waveforms are normal
Replace X401

Replace U401

NO
YES
