LG FLATRON E2040S - TROUBLESHOOTING: POWER SUPPLY FAILURES; AC INPUT AND ADAPTER CHECKS; INTERNAL POWER BOARD AND PANEL ISSUES


Copyright © 2010 LG Electronics. Inc. All right reserved. - 22 - LGE Internal Use Only
Only for training and service purposes
5. POWER
Replace panel
Check Vout about
35V?
Check L801,D801,Q801
NO
YES
Check
CN701=12V?

Check FB701,C716

YES
NO
YES
No Power
(Power Indicator Off)
Check AC line
volt
Check the
adapter
Check AC line & AC
soc
k
et
Replace adapter
NO
YES
NO
Check main board

Checkmainboard
NO
