LG Flatron F700P User Manual

- 24 -
DATE: 2002. 5. 14.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C201 0CN1040K949 0.1M 50V Z F TA52
C301 0CE477CF618 470UF SHL 16V M FL TP5
C302 0CE107CF638 100UF SHL,SD 16V M FM5 TP 5
C303 181-288B MKT 100V 104JTR PHS26104
C304 181-288N MKT 100V 103JTR PHS86103
C305 181-288N MKT 100V 103JTR PHS86103
C306 0CN1040K949 0.1M 50V Z F TA52
C307 0CN1040K949 0.1M 50V Z F TA52
C308 0CN1040K949 0.1M 50V Z F TA52
C309 181-288B MKT 100V 104JTR PHS26104
C310 0CK1040K945 0.1UF 50V Z F TR
C312 181-288B MKT 100V 104JTR PHS26104
C313 181-288B MKT 100V 104JTR PHS26104
C314 181-288B MKT 100V 104JTR PHS26104
C315 181-288B MKT 100V 104JTR PHS26104
C316 0CK10302940 0.01M 2KV Z F S
C317 0CE106CN638 10UF SHL,SD 100V M FM5 TP 5
C318 181-288B MKT 100V 104JTR PHS26104
C319 0CK10302940 0.01M 2KV Z F S
C320 0CE107CN630 100U SHL 100V M FM5
C321 0CE107EF638 100UF KMG 16V M FM5 TP 5
C322 0CN1040K949 0.1M 50V Z F TA52
C323 0CE476EN618 47UF KMG 100V M FL TP 5
C324 181-288B MKT 100V 104JTR PHS26104
C325 0CC3300K415 33P 50V J NP0 TP
C326 181-288B MKT 100V 104JTR PHS26104
C327 181-288B MKT 100V 104JTR PHS26104
C329 181-288B MKT 100V 104JTR PHS26104
C330 181-288B MKT 100V 104JTR PHS26104
C332 181-288E MKT 100V 474JTR PHS 26474
C333 181-288E MKT 100V 474JTR PHS 26474
C334 181-288E MKT 100V 474JTR PHS 26474
C336 0CK1010W515 100P 500V K B TS
C337 181-288B MKT 100V 104JTR PHS26104
C340 0CE227CF638 220UF SHL,SD 16V M FM5 TP 5
C341 181-288B MKT 100V 104JTR PHS26104
C342 0CC2200W415 22PF 500V J NP0 TR
C343 0CK1010K515 100PF 50V K B TR
C345 0CK22202510 2200P 2KV K B S
C346 0CC47001505 47PF 1KV K SL TR
C347 0CC47001505 47PF 1KV K SL TR
C348 0CK1040K945 0.1UF 50V Z F TR
C349 181-288E MKT 100V 474JTR PHS 26474
C350 0CK2210K515 220P 50V K B TS
C355 0CK1040K945 0.1UF 50V Z F TR
C356 0CN6810K519 680P 50V K B TA52
C401 0CC5600K415 56P 50V J NP0 TP
C402 0CE476CH638 47UF SHL,SD 25V M FM5 TP 5
DATE: 2002. 5. 14.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C403 0CK2710K515 270P 50V K B TS
C404 0CK2710K515 270P 50V K B TS
C405 0CK2710K515 270P 50V K B TS
C406 0CC0400K115 4P 50V D NP0 TS
C407 0CC0400K115 4P 50V D NP0 TS
C408 0CN1040K949 0.1M 50V Z F TA52
C410 0CK1040K945 0.1UF 50V Z F TR
C417 0CK1040K945 0.1UF 50V Z F TR
C418 0CN1040K949 0.1M 50V Z F TA52
C452 0CE106CK638 10UF SHL,SD 50V M FM5 TP 5
C453 0CE106CK638 10UF SHL,SD 50V M FM5 TP 5
C454 0CK1040K945 0.1UF 50V Z F TR
C455 0CK1040K945 0.1UF 50V Z F TR
C456 0CE106CK638 10UF SHL,SD 50V M FM5 TP 5
C457 0CK1040K945 0.1UF 50V Z F TR
C459 0CK1010K515 100PF 50V K B TR
C501 0CE1074F638 100UF SRA,SS 16V M FM5 TP 5
C502 0CE1074F638 100UF SRA,SS 16V M FM5 TP 5
C503 0CE4754K638 4.7M SRA 50V M FM5 TP(5)
C504 0CE1074F638 100UF SRA,SS 16V M FM5 TP 5
C505 0CH6330K416 33PF 50V J NP0 2012 R/TP
C506 0CH6330K416 33PF 50V J NP0 2012 R/TP
C507 0CE1054K638 1 UF SRA,SS 50V M FM5 TP 5
C508 0CH3104K946 100000PF 50V Z F 2012 R/TP
C509 0CH3103K516 10000PF 50V K B 2012 R/TP
C510 0CH3104K946 100000PF 50V Z F 2012 R/TP
C511 0CE1054K638 1 UF SRA,SS 50V M FM5 TP 5
C512 0CH3104K946 100000PF 50V Z F 2012 R/TP
C513 0CH3104K946 100000PF 50V Z F 2012 R/TP
C514 0CH3104K946 100000PF 50V Z F 2012 R/TP
C515 0CH3104K946 100000PF 50V Z F 2012 R/TP
C516 0CE1074F638 100UF SRA,SS 16V M FM5 TP 5
C601 0CQ4721N419 0.0047U 100V J POLY NI TP5
C602 0CE225CK638 2.2UF SHL,SD 50V M FM5 TP 5
C603 0CN2220K519 2200PF 50V K B TA52
C604 0CN1040K949 0.1M 50V Z F TA52
C605 181-288Q MKT 100V 154JTR PHS26154
C606 0CK2220W515 2200P 500V K B TS
C608 0CE108CF618 1000UF SHL 16V M FL TP5
C610 0CE227EK618 220UF KMG 50V M FL TP 5
C611 0CE108CH618 1000UF SHL 25V M FL TP5
C615 181-288Q MKT 100V 154JTR PHS26154
C616 0CQ1231N419 0.0120UF 100V J PE NI TP
C619 0CE475CN638 4.7UF SHL,SD 100V M FM5 TP 5
C701 0CE106CK638 10UF SHL,SD 50V M FM5 TP 5
C702 0CE227EN630 220UF KMG 100V M FM5 BULK
C704 0CBZTBU003J 392J 20.0*12.5*7.5*10.0 800V J
C705 0CE336CN638 33UF SHL,SD 100V M FM5 TP 5
C707 0CE106CK638 10UF SHL,SD 50V M FM5 TP 5
REPLACEMENT PARTS LIST
CAUTION: BEFORE REPLACING ANY OF THESE COMPONENTS,
READ CAREFULLY THE SAFETY PRECAUTIONS IN THIS MANUAL.
* NOTE : S SAFETY Mark
AL ALTERNATIVE PARTS
CAPACITORS

LG Flatron F700P Specifications

Display

colours	16.7 million
pitch	0.24
max resolution	1920 x 1440 @ 65 Hz
recommended resolution	1280 x 1024 @ 85 Hz

Frequency

horizontal frequency	30 ~ 98 KHz
vertical frequency	50 ~ 160 Hz

Power

power supply	AC 90-264 V, 47~63 Hz
DPMS power consumption (on)	<83 W
DPMS power consumption (stand-by)	<8 W
DPMS power consumption (off)	<5 W

Weight and Dimensions

visual area	325 x 244 mm
dimensions	415 x 432 x 413 mm (net)
weight	17 kg (net), 20.5 kg (box)
