LG Flatron F700P User Manual

PIN CONFIGURATION
- 31 -
PWM output terminal
Power supply terminal
Trigger Input terminal
This pin is used to set oscillating frequency
This pin is used for AGC setting
Output terminal of error signal
Input terminal of Over Voltage Protection
Input terminal of Under Voltage Protection
Postive Input terminal of Buffer Amp
Output terminal of Buffer Amp
Postive Input terminal of OP Amp
Negative Input terminal of OP Amp
Output terminal of OP Amp
Dead time control terminal(Soft start function)
Output terminal of reference voltage (5V)
Ground terminal
M62501P /FP
M62501
1
2
3
4
5
6
7
8
PWM OUT
Vcc
TIN
Cosc
Cagc
POUT
OVP
UVP
GND
VREF
DTC
FB
IN -
IN +
BO
BI
16
15
14
13
12
11
10
9
PIN CONFIGURATION(TOP VIEW)
Outlone P: 16P4
FP: 16P2S
PIN NO.
Symbol
PWM OUT
Vcc
TIN
CAGC
CAGC
P.OUT
OVP
UVP
BI
BO
IN
+
IN
-
FB
DTC
VREF
GND
Functional Description
Teerminal Number and The facillty
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
TDA8172 Vertical Deflection Output Circuit
1
7
7
6
5
4
3
2
1
NON-INVERTING INPUT
OUTPUT STAGE SUPPLY
OUYPUT
GROUND
FLYBACK GENERATOR
SUPPLY VOLTAGE
INVERTING INPUT
Pin Configuration
M24C08 Serial I
2
C BUS EEPROM
SYMBOL
E0-E2
SDA
SCL
WC
Vcc
Vss
DESCRIPTION
Chip Enable Input
Serial Data Address Input/Output
Serial Clock
Write Control
Supply Voltage
Ground
1
PSDIP8 (BN)
0.25mm Frame
8
1
1
SO8 (MN)
150mil Width
TSSOP8 (DW)
169mil Width
8
8
Logic Dirgram

LG Flatron F700P Specifications

Display

colours	16.7 million
pitch	0.24
max resolution	1920 x 1440 @ 65 Hz
recommended resolution	1280 x 1024 @ 85 Hz

Frequency

horizontal frequency	30 ~ 98 KHz
vertical frequency	50 ~ 160 Hz

Power

power supply	AC 90-264 V, 47~63 Hz
DPMS power consumption (on)	<83 W
DPMS power consumption (stand-by)	<8 W
DPMS power consumption (off)	<5 W

Weight and Dimensions

visual area	325 x 244 mm
dimensions	415 x 432 x 413 mm (net)
weight	17 kg (net), 20.5 kg (box)
