LG Flatron F700P User Manual

DATE: 2002. 5. 14.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R837 0RN1202F409 12K 1/6W 1% TA52
R838 0RD0101Q609 1 1/4W(3 5% TA52
R841 0RD5601Q609 5.60K 1/4W(3 5% TA52
R842 0RMZTWD001A 4.7 OHM 5 W 5% B RWR
R843 0RX1003J609 100KOHM 1 W 5% TA52
R846 0RD0332A609 33 OHM 1/2 W (7.0) 5% TA52
R847 0RD1000A609 100 OHM 1/2 W (7.0) 5% TA52
R848 0RD0471A609 4.7 OHM 1/2 W (7.0) 5% TA52
R849 0RX1300J609 130 OHM 1 W 5% TA52
R850 0RMZTWD001C 47 OHM 7 W 5% RWR PD-TYPE
R851 0RD4701Q609 4.70K 1/4W(3 5% TA52
R853 0RD4701Q609 4.70K 1/4W(3 5% TA52
R855 0RD4701Q609 4.70K 1/4W(3 5% TA52
R857 0RD3001Q609 3K 1/4W(3 5% TA52
R859 0RD0102Q609 10 1/4W(3 5% TA52
R860 0RD2000Q609 200 1/4W(3 5% TA52
R861 180-465Y RWR 1.2OHM 7W.(V-TYPE)
R862 0RN0390J607 0.39 1W 5% TA62
R871 0RX1800K607 180 OHM 2 W 5% TA62
R872 0RD2401Q609 2.40K 1/4W(3 5% TA52
R873 0RD0122A609 12 OHM 1/2 W (7.0) 5% TA52
R874 0RX0332K607 33 OHM 2 W 5% TA62
R875 0RX0432K607 43 OHM 2 W 5% TA62
R876 0RN3002F409 30K 1/6W 1% TA52
R891 0RN2701F409 2.70K 1/6W 1% TA52
R892 0RN6800F409 680 1/6W 1% TA52
R893 0RD3301Q609 3.30K 1/4W(3 5% TA52
R894 0RN2202F409 22K 1/6W 1% TA52
R895 0RD1000Q609 100 1/4W(3 5% TA52
R896 0RD1000Q609 100 1/4W(3 5% TA52
R901 180-465H 0.24 OHM 5W 5% (NON PFC)
R902 0RD0472Q609 47 1/4W(3 5% TA52
R903 0RD0752Q609 75 1/4W(3 5% TA52
R905 0RX4702K665 47K OHM 2 W 5% SF
R908 0RN0220H609 0.22 1/2W 5% TA52
R909 0RD1002Q609 10K 1/4W(3 5% TA52
R910 0RD1802Q609 18K 1/4W(3 5% TA52
R911 0RN6800F409 680 1/6W 1% TA52
R912 0RD1001Q609 1K 1/4W(3 5% TA52
R913 0RB0120K607 0.12 OHM 2 W 5% TA62
R914 0RD1500Q609 150 1/4W(3 5% TA52
R915 0RD8203Q609 820KOHM 1/4 W (3.4) 5% TA52
R916 0RD8203Q609 820KOHM 1/4 W (3.4) 5% TA52
R917 0RD1000Q609 100 1/4W(3 5% TA52
R918 0RD1003Q609 100K 1/4W(3 5% TA52
R919 0RD2002Q609 20K 1/4W(3 5% TA52
R920 0RD0332Q609 33 1/4W(3 5% TA52
R921 0RD0332Q609 33 1/4W(3 5% TA52
R922 0RD5101Q609 5.10K 1/4W(3 5% TA52
R924 0RD1500Q609 150 1/4W(3 5% TA52
R925 0RD1001Q609 1K 1/4W(3 5% TA52
R926 0RD4701Q609 4.70K 1/4W(3 5% TA52
R928 0RX0331K607 3.3 OHM 2 W 5% TA62
R941 0RD2703A609 270K OHM 1/2 W (7.0) 5% TA52
R942 971-0054 TIN 50MM TAPING
R949 0RN0220H609 0.22 1/2W 5% TA52
R950 0RD1002Q609 10K 1/4W(3 5% TA52
DATE: 2002. 5. 14.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R951 0RD1101A609 1.1K OHM 1/2 W (7.0) 5% TA52
R952 0RD4701Q609 4.70K 1/4W(3 5% TA52
R953 0RD1002Q609 10K 1/4W(3 5% TA52
R954 0RD4700A609 470 OHM 1/2 W (7.0) 5% TA52
R955 0RD4701Q609 4.70K 1/4W(3 5% TA52
R961 0RD3900Q609 390 1/4W(3 5% TA52
R970 0RX4702K607 47KOHM 2 W 5% TA62
R971 0RD2703Q609 270K 1/4W(3 5% TA52
R972 0RD2703Q609 270K 1/4W(3 5% TA52
R973 0RD0392Q609 39 1/4W(3 5% TA52
R974 0RB0101J609 1 OHM 1 W 5% TA52
R975 0RD0222Q609 22 1/4W(3 5% TA52
R976 0RD1000Q609 100 1/4W(3 5% TA52
R977 0RD4701Q609 4.70K 1/4W(3 5% TA52
R978 0RN1501F409 1.5K 1/6W 1 TA52
R979 0RN1501F409 1.5K 1/6W 1 TA52
R981 0RD1001Q609 1K 1/4W(3 5% TA52
R990 0RD0512Q609 51 1/4W(3 5% TA52
R991 0RD5101Q609 5.10K 1/4W(3 5% TA52
R992 0RD5101Q609 5.10K 1/4W(3 5% TA52
F901 0FZZTTH001B TIME LAG HBC 5A/250V,215 005,L
J113 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
J313 0RD0152Q609 15 1/4W(3 5% TA52
J331 0RD0152Q609 15 1/4W(3 5% TA52
J332 0RD0152Q609 15 1/4W(3 5% TA52
J43 0RD4700Q609 470 OHM 1/4 W (3.4) 5% TA52
J82 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
RL901 6920TBB006A DY3M-DC12V DONGYANG 250VAC 5A
SC301 6620TBD003A PCS701E PARK ELEC. 10PIN 14/36
SC901 6200TJB001H 02MD1 DELTA BK W/O GND
SG301 6918TAT005E MTAS-201M GIGA AXIAL TAPING
SG302 165-004A AG20PT 152F-L3N/S-23 HANDOK RA
SG303 6918TAT005E MTAS-201M GIGA AXIAL TAPING
SG304 6918TAT005E MTAS-201M GIGA AXIAL TAPING
SG305 6918TAT005E MTAS-201M GIGA AXIAL TAPING
SG701 165-004A AG20PT 152F-L3N/S-23 HANDOK RA
SW201 140-058D SKHV10911A LGEC NON 12 20 HORI
SW202 140-058D SKHV10911A LGEC NON 12 20 HORI
SW203 140-058D SKHV10911A LGEC NON 12 20 HORI
SW204 140-058D SKHV10911A LGEC NON 12 20 HORI
SW205 140-058D SKHV10911A LGEC NON 12 20 HORI
SW206 140-058D SKHV10911A LGEC NON 12 20 HORI
SW207 140-058D SKHV10911A LGEC NON 12 20 HORI
SW801 140-079C SLS-1301 SW NON 30 0 HORIZENTA
T701 6174T13010C “FQM19A008,EB990G SAMSUNG 19”””
T801 6140TDZ009A - GET EER2834,DUMMY,EB990G
T802 6170TCZ008A EE2218 1.3MH FB995C
T901 6170TMZ130A EER4445S 135UH V-18PIN EB990G
T903 6170TMZ131A EE2525F 820UH V-10PIN EB790G S
TH901 6322TB4R51A J503P61D4R5Q270S JAHWA 4.5 oh
TH902 6322TA080AB
TP8D15 DAEWOO +/- 15% 110/220V (NON PFC)
VR801 180-035Q EVN-DJAA03B24 (MEC),20KB
VR901 180-035C EVN-DJAA03B22 (MEC),200B
X401 6202TTB003B HC-49/U HARMONY RADIAL 12MHZ 3
X501 6202TTB001A HC-49/U SUNNY E 6.000000MHZ 30
- 30 -
OTHERs

LG Flatron F700P Specifications

Display

colours	16.7 million
pitch	0.24
max resolution	1920 x 1440 @ 65 Hz
recommended resolution	1280 x 1024 @ 85 Hz

Frequency

horizontal frequency	30 ~ 98 KHz
vertical frequency	50 ~ 160 Hz

Power

power supply	AC 90-264 V, 47~63 Hz
DPMS power consumption (on)	<83 W
DPMS power consumption (stand-by)	<8 W
DPMS power consumption (off)	<5 W

Weight and Dimensions

visual area	325 x 244 mm
dimensions	415 x 432 x 413 mm (net)
weight	17 kg (net), 20.5 kg (box)
