LG flatron M1740A Service Manual

- 21 -
EXPLODED VIEW PARTS LIST
010
020
030
040
050
060
070
080
090
100
110
120
130
140
3091TKL150B CABINET ASSEMBLY, M1740A BRAND 3090TKL127 MFM A-CKD-For Europe,U.K
3091TKL150K CABINET ASSEMBLY, M1740A BRAND 3090TKL127 MFM J CKD-For Russia
3091TKL151B CABINET ASSEMBLY, M1940A BRAND 3090TKL129 MFM A-CKD-For Europe,U.K
3091TKL151K CABINET ASSEMBLY, M1940A BRAND 3090TKL129 MFM J-CKD-For Russia
3091TKL152B CABINET ASSEMBLY, M2040A BRAND 3090TKL131 MFM B-CKD-For Europe,U.K
3091TKL152K CABINET ASSEMBLY, M2040A BRAND 3090TKL131 MFM J-CKD-For Russia
6304FLP261A
LCD(LIQUID CRYSTAL DISPLAY), LM170E01-TL12 LG PHILPS TFT COLOR DOT FREE,PB FREE,GLARE,TN,420NITS,8MS,LAMP UNLOCKING,SXGA,LVDS
or 6304FLP202A
LCD(LIQUID CRYSTAL DISPLAY), LM170E01-TL11 LG PHILPS TFT COLOR PB FREE,GLARE,TN,420NITS,8MS,LAMP UNLOCKING,SXGA,LVDS
6304FLP197A LCD(LIQUID CRYSTAL DISPLAY), LM190E03-A4K2 LG PHILPS TFT COLOR GLARE,TN,400NITS,12MS,SOUND VIBRATION,20T,SXGA,LVDS
or 6304FLP262A LCD(LIQUID CRYSTAL DISPLAY), LM190E03-A4K6 LG PHILPS TFT COLOR DOT FREE,PB FREE OF A4K2,GLARE,TN,400NITS,12MS,SOUND VIBRATION,20T
6304FLP282A LCD(LIQUID CRYSTAL DISPLAY), LM201U04-SL03 LG PHILPS TFT COLOR P6,GLARE,300NITS,16MS,PB FREE,UXGA,8BITS,LVDS,4MASK
3809TKL105B BACK COVER ASSEMBLY, M1740A 3808TKL105 MFM A-CKD
3809TKL106B BACK COVER ASSEMBLY, M1940A 3808TKL106 MFM A-CKD
3809TKL107B BACK COVER ASSEMBLY, M2040A 3808TKL107 MFM A-CKD
3043900013F TILT SWIVEL ASSEMBLY, M1740 . 226U-(E-CKD)SLIVER SPRAY
3043TKK230F TILT SWIVEL ASSEMBLY, M1940A . SILVER, E-CKD-M2040A
6400ZTTE01A
SPEAKER,FULLRANGE, KTA-N1040-1 TOPTONE OTHERS 16OHM 3/5W .DB 100 TW+WF,M1740A,M1940A
6400ZTTS01A SPEAKER,FULLRANGE, KTA-N1527-1 TOPTONE OTHERS 16OHM 5/7W .DB 70 TW+WF,M2040A
6871TST914A PWB(PCB) ASSEMBLY,SUB, M1740A/M1940A/M2040A CONTROL TOTAL BRAND KEY
6871TSP685B PWB(PCB) ASSEMBLY,SUB, M1740A/M1940A/M2040A LED & P/SW SMD TOP BRAND TOUCH
4951TKS189F METAL ASSEMBLY, FRAME MAIN ASSY M1740A E-CKD
4951TKS190F METAL ASSEMBLY, FRAME MAIN ASSY M1940A E-CKD
4951TKS207D METAL ASSEMBLY, FRAME M2040A MAIN FRAME,SUPPORT(B-CKD)
6871TPT281E
PWB(PCB) ASSEMBLY,POWER, AUTOBAHN 15(LPL,CMO,HYDIS) & L173SAB(MFM) LPL POWER TOTAL SPI LIPS.-M1740A,M1940A
6871TPT280G
PWB(PCB) ASSEMBLY,POWER, M203WTB(CARD READER) POWER TOTAL LIEN CHANG LIPS FOR LPL 20.1-M2040A
3313TL7102A MAIN TOTAL ASSEMBLY, M1740A-RZB-ANRDLF BRAND CL-74
3313TL9093A MAIN TOTAL ASSEMBLY, M1940A-RZB-ANRDLF BRAND CL-74
3313TL2036A MAIN TOTAL ASSEMBLY, M2040A-RZB-ANRDLF BRAND CL-75
4950TKA149D METAL, FRAME ,REAR(M1740A) A-CKD
4950TKA149C METAL, FRAME ,REAR(M1940A) B-CKD
4950TKA154A METAL, FRAME ,REAR M2040T
6871TVT386A PWB(PCB) ASSEMBLY,VIDEO, M1740A/M1940A VIDEO TOTAL BRAND CVBS
6871TVT386B PWB(PCB) ASSEMBLY,VIDEO, M2040A VIDEO TOTAL BRAND CVBS
3550TKK793B COVER, M1740T REAR DOOR A-CKD
3550TKK794B COVER, M1940T REAR DOOR A-CKD
3550TKK795B COVER, M2040A REAR DOOR CKD
6410TEW010A
POWER CORD LP34A+LS60 LONGWELL VDE/SEMKO 1870MM WALL CD/PB FREE BLACK-For Europe
6410TPW003A POWER CORD LP-33+LS-60 LONGWELL PCT 1870MM WALL CD/PB FREE BLACK-For Russia
6410TBW004A POWER CORD LP-61+LS-60 LONGWELL BSI 1870MM WALL CD/PB FREE BLACK-For U.K
Description
Part No.
Ref. No.
