LG flatron M1740A Service Manual

- 22 -
DATE: 2005. 11. 30.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C101 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C102 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C103 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C104 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C105 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C106 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C107 0CC100CK41A 10PF 1608 50V 5% R/TP NP0
C108 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C109 0CH6101K416 100PF 50V 5% NP0 2012 R/TP
C110 0CH6101K416 100PF 50V 5% NP0 2012 R/TP
C111 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C112 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C113 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C114 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C115 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C116 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C117 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C118 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C119 0CH6680K416 68PF 2012 50V 5% NP0 R/TP
C120 0CH6101K416 100PF 50V 5% NP0 2012 R/TP
C121 0CH6101K416 100PF 50V 5% NP0 2012 R/TP
C122 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C125 0CC471CK41A 470PF 1608 50V 5% R/TP NP0
C128 0CC471CK41A 470PF 1608 50V 5% R/TP NP0
C150 0CH8106F691 10UF 16V 20% 105STD (CYL) R/
C151 0CH6102K406 1000PF 50V 5% SL 2012 R/TP
C152 0CH6102K406 1000PF 50V 5% SL 2012 R/TP
C153 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C154 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C155 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C156 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C157 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C158 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C201 0CH8476H691 47UF 25V 20% 105STD (CYL) R/
C202 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C203 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C204 0CC221CK41A 220PF 1608 50V 5% R/TP NP0
C205 0CH6102K406 1000PF 50V 5% SL 2012 R/TP
C206 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C207 0CK105CF94A "1UF 1608 16V 80%,-20% R/TP F"
C208 0CH3105H946 "1UF 2012 25V 80%,-20% F(Y5V)"
C209 0CH6102K406 1000PF 50V 5% SL 2012 R/TP
C210 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C211 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C212 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C213 0CH6102K406 1000PF 50V 5% SL 2012 R/TP
C214 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C215 0CH6102K406 1000PF 50V 5% SL 2012 R/TP
C216 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C217 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C218 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C219 0CK105CF94A "1UF 1608 16V 80%,-20% R/TP F"
DATE: 2005. 11. 30.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C220 0CK105CF94A "1UF 1608 16V 80%,-20% R/TP F"
C221 0CH3105H946 "1UF 2012 25V 80%,-20% F(Y5V)"
C222 0CK105CF94A "1UF 1608 16V 80%,-20% R/TP F"
C223 0CK105CF94A "1UF 1608 16V 80%,-20% R/TP F"
C224 0CK105CF94A "1UF 1608 16V 80%,-20% R/TP F"
C225 0CH3105H946 "1UF 2012 25V 80%,-20% F(Y5V)"
C226 0CH8476H691 47UF 25V 20% 105STD (CYL) R/
C227 0CH8476H691 47UF 25V 20% 105STD (CYL) R/
C228 0CH3474H946 "0.47UF 25V 80%,-20% F(Y5V) 2"
C230 0CE227EF638 "220UF KMG,RD 16V 20% TP 5 FM"
C231 0CE227EF638 "220UF KMG,RD 16V 20% TP 5 FM"
C232 0CH8106F691 10UF 16V 20% 105STD (CYL) R/
C250 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C251 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C252 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C253 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C254 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C255 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C256 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C257 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C258 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C259 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C260 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C261 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C262 0CK102CK56A 1000PF 1608 50V 0.1 R/TP X7R
C401 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C402 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C403 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C404 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C405 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C406 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C407 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD)
C408 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C409 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C410 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C411 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C424 0CC220CK41A 22PF 1608 50V 5% R/TP NP0
C425 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C430 0CH8106F691 10UF 16V 20% 105STD (CYL) R/
C464 0CC220CK41A 22PF 1608 50V 5% R/TP NP0
C470 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C471 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C472 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C473 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C474 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C475 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C476 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C477 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C478 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C479 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C480 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C481 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C482 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C483 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
REPLACEMENT PARTS LIST
CAUTION: BEFORE REPLACING ANY OF THESE COMPONENTS,
READ CAREFULLY THE SAFETY PRECAUTIONS IN THIS MANUAL.
* NOTE : S SAFETY Mark
AL ALTERNATIVE PARTS
MAIN BOARD
CAPACITORS
