LG flatron M1740A Service Manual

DATE: 2005. 11. 30.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R101 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R102 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R103 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R104 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R105 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R106 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R107 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R108 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R109 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R110 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R111 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R112 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R113 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R114 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R115 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R116 0RH4700D622 470 OHM 1 / 10 W 2012 5.00%
R117 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R118 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R119 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R120 0RJ8200D677 820 OHM 1/10 W 5% 1608 R/TP
R121 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R122 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R123 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R124 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R126 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R127 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R128 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R129 0RH0222D622 22 OHM 1 / 10 W 2012 5.00% D
R130 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R131 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R132 0RH0472D622 47 OHM 1 / 10 W 2012 5.00% D
R133 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R134 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R135 0RH0222D622 22 OHM 1 / 10 W 2012 5.00% D
R136 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R137 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R139 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R141 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R142 0RJ0562D677 56 OHM 1/10 W 5% 1608 R/TP
R143 0RJ0562D677 56 OHM 1/10 W 5% 1608 R/TP
R147 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R148 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R149 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R150 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
R204 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R205 0RJ1203D677 120K OHM 1/10 W 5% 1608 R/TP
R206 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R207 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R209 0RH4702D622 47K OHM 1 / 10 W 2012 5.00%
R210 0RJ1202D677 12K OHM 1/10 W 5% 1608 R/TP
R211 0RJ6801D677
6800 OHM 1/10 W 5% 1608 R/TP X7R-M1710A,M1910A
R211 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP-M2040A
R214 0RJ6801D677
6800 OHM 1/10 W 5% 1608 R/TP X7R-M1710A,M1910A
R214 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP-M2040A
R215 0RJ1802D677 18K OHM 1/10 W 5% 1608 R/TP
R217 0RH1502D622 15K OHM 1 / 10 W 2012 5.00%
R218 0RH4702D622 47K OHM 1 / 10 W 2012 5.00%
R219 0RJ2002D677
20000 OHM 1/10 W 5% 1608 R/T X7R-M1710A,M1910A
R219 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP-M2040A
R220 0RJ2002D677
20000 OHM 1/10 W 5% 1608 R/T X7R-M1710A,M1910A
R220 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP-M2040A
DATE: 2005. 11. 30.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R221 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R222 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R223 0RH1001D622 1K OHM 1 / 10 W 2012 5.00% D
R224 0RH1001D622 1K OHM 1 / 10 W 2012 5.00% D
R225 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R226 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R230 0RH1002D422 10K OHM 1/10 W 1% 2012 R/TP
R231 0RH1002D422 10K OHM 1/10 W 1% 2012 R/TP
R232 0RH1500D622 150 OHM 1 / 10 W 2012 5.00%
R240 0RJ1203D677 120K OHM 1/10 W 5% 1608 R/TP
R243 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R244 0RH1001D622 1K OHM 1 / 10 W 2012 5.00% D
R245 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R246 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R247 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R4001 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R4002 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
R4003 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
R4004 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
R4005 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
R4006 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
R4007 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
R401 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R4012 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R4013 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R402 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R403 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
R404 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R405 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
R406 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R407 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R409 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R410 0RH2700D422 270 1/10W 1% D R/TP
R411 0RH0222D622 22 OHM 1 / 10 W 2012 5.00% D
R412 0RH0222D622 22 OHM 1 / 10 W 2012 5.00% D
R413 0RH0222D622 22 OHM 1 / 10 W 2012 5.00% D
R414 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R415 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R418 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R419 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R420 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00%
R422 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R423 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R424 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R425 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R426 0RH2701D622 2.7K OHM 1 / 10 W 2012 5.00%
R428 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R430 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R431 0RH3301D622 3.3K OHM 1 / 10 W 2012 5.00%
R432 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R433 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R434 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R435 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R436 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R437 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R440 0RH3301D622 3.3K OHM 1 / 10 W 2012 5.00%
R441 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R442 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R443 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R445 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R446 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R447 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
- 26 -
RESISTORs
