LG flatron M1740A Service Manual

DATE: 2005. 11. 30.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R819 0RH1501D622 1.5K OHM 1 / 10 W 2012 5.00%
R820 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R821 0RH8200D622 820 OHM 1 / 10 W 2012 5.00%
R822 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R823 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R824 0RH3000D622 300 OHM 1 / 10 W 2012 5.00%
R825 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R826 0RJ1802D677 18K OHM 1/10 W 5% 1608 R/TP
R827 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R828 0RH0752D622 75 OHM 1 / 10 W 2012 5.00% D
R829 0RH0752D622 75 OHM 1 / 10 W 2012 5.00% D
R830 0RH0752D622 75 OHM 1 / 10 W 2012 5.00% D
R831 0RH0752D622 75 OHM 1 / 10 W 2012 5.00% D
R832 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R833 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R834 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R835 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R836 0RJ2700D677 270 OHM 1/10 W 5% 1608 R/TP
R837 0RH0682D622 68 OHM 1 / 10 W 2012 5.00% D
R838 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R839 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R852 0RJ3301D677 3.3K OHM 1/10 W 5% 1608 R/TP
R853 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R854 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R857 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R858 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R859 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R860 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R861 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R862 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/T
R870 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R871 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R872 0RJ1003D677 100K OHM 1/10 W 5% 1608 R/TP
R873 0RJ1003D677 100K OHM 1/10 W 5% 1608 R/TP
R874 0RJ1003D677 100K OHM 1/10 W 5% 1608 R/TP
R875 0RJ1003D677 100K OHM 1/10 W 5% 1608 R/TP
R877 0RJ1003D677 100K OHM 1/10 W 5% 1608 R/TP
R878 0RJ1003D677 100K OHM 1/10 W 5% 1608 R/TP
R879 0RH1003D622 100K OHM 1 / 10 W 2012 5.00%
R880 0RH1003D622 100K OHM 1 / 10 W 2012 5.00%
R901 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R902 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R903 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/T
R904 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R905 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R906 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R907 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP
R908 0RJ5600D677 560 OHM 1/10 W 5% 1608 R/TP
R911 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R912 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP
R913 0RJ5600D677 560 OHM 1/10 W 5% 1608 R/TP
R914 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R915 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP
R916 0RH5600D622 560 OHM 1 / 10 W 2012 5.00%
R917 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R918 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R919 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R920 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R921 0RH1001D622 1K OHM 1 / 10 W 2012 5.00% D
R922 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R923 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R924 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
DATE: 2005. 11. 30.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R925 0RB0470K607 0.47 OHM 2 W 5% TA62
R926 0RB0470K607 0.47 OHM 2 W 5% TA62
R927 0RJ0000D677
0 OHM 1/10 W 5% 1608 R/TP X7R-M1710A,M1910A
R928 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP X7R-M1710A,M1910A
R929 0RJ5600D677
560 OHM 1/10 W 5% 1608 R/TP X7R-M1710A,M1910A
R930 0RJ1002D677
10K OHM 1/10 W 5% 1608 R/TP X7R-M1710A,M1910A
R931 0RJ0000D677
0 OHM 1/10 W 5% 1608 R/TP X7R-M1710A,M1910A
R932 0RJ5602D477 56K OHM 1/10 W 1% 1608 R/TP-M2040A
R933 0RJ1803D677 180K OHM 1/10 W 5% 1608 R/TP-M2040A
R934 0RJ1302D677 13K OHM 1/10 W 5% 1608 R/TP-M2040A
R936 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP-M2040A
R940 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R941 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP
R942 0RJ5600D677 560 OHM 1/10 W 5% 1608 R/TP
R944 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R945 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP
R946 0RJ5600D677 560 OHM 1/10 W 5% 1608 R/TP
R947 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R948 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
RA401 0RHZTCZ001D RCA SMART 22OHM 1/16 W 5% 32
RA402 0RHZTCZ001D RCA SMART 22OHM 1/16 W 5% 32
RA403 0RHZTCZ001D RCA SMART 22OHM 1/16 W 5% 32
RA404 0RHZTCZ001D RCA SMART 22OHM 1/16 W 5% 32
RA405 0RHZTCZ001D RCA SMART 22OHM 1/16 W 5% 32
RA406 0RHZTCZ001D RCA SMART 22OHM 1/16 W 5% 32
RA407 0RHZTCZ001D RCA SMART 22OHM 1/16 W 5% 32
RA408 0RHZTCZ001D RCA SMART 22OHM 1/16 W 5% 32
RA409 0RHZTCZ001D RCA SMART 22OHM 1/16 W 5% 32
RA410 0RHZTCZ001D RCA SMART 22OHM 1/16 W 5% 32
RA411 0RHZTCZ001D RCA SMART 22OHM 1/16 W 5% 32
TU802 6700VS0003E TAEW-G053D LGIT MULTI VS PAL
U403 6620F00017A CCSD-32T-SM WOOYOUNG 32P PLC
X401 6202TST001A "SX-1 SUNNY ,SMS, 14.31818MHZ"
X601 6202TST003C HC-49/SM5H KONY CHIP 20.25MH
U501 6712SCA233A "TSOP4838VI1 VISHAY 38KHZ 5V,"
C501 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C502 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C503 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
R501 0RJ1201D677 1200 OHM 1/10 W 5% 1608 R/TP
R502 0RJ1200D677 120 OHM 1/10 W 5% 1608 R/TP
R503 0RJ1600D677 160 OHM 1/10 W 5% 1608 R/TP
R504 0RJ2000D677 200 OHM 1/10 W 5% 1608 R/TP
R505 0RJ2700D677 270 OHM 1/10 W 5% 1608 R/TP
R506 0RJ3600D477 360 OHM 1/10 W 1% 1608 R/TP
R507 0RJ5600D677 560 OHM 1/10 W 5% 1608 R/TP
R508 0RJ8200D677 820 OHM 1/10 W 5% 1608 R/TP
SW501 6600R00004A JTP1138A6EM JEIL 12VDC 50MA
SW502 6600R00004A JTP1138A6EM JEIL 12VDC 50MA
SW503 6600R00004A JTP1138A6EM JEIL 12VDC 50MA
SW504 6600R00004A JTP1138A6EM JEIL 12VDC 50MA
SW505 6600R00004A JTP1138A6EM JEIL 12VDC 50MA
SW506 6600R00004A JTP1138A6EM JEIL 12VDC 50MA
SW507 6600R00004A JTP1138A6EM JEIL 12VDC 50MA
ZD501 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323
ZD504 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323
C901 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
- 28 -
OTHERs
CONTROL BOARD
