- 20 -
2. NO RASTER (OSD IS NOT DISPLAY)-LIPS
LIPS
Check U704 PIN 2
1.8V?
1. Check U704
2. Check C704
3. TROUBLE IN SCALER IC
NO
No Raster
(OSD Is Not Displayed)
Check U703
PIN 2 =3.3V?
Check CN701
PIN 6, PIN7 =5V?
Check power board and find out a
short point as penning each power
line
1. Check U703
2. Check C706,C707
NO
NO
YES
YES
YES
Check CN701
PIN 6, PIN7 =5V?
YES
NO
Check BL ON/OFF pulse as
contacting scope
