- 27 -
EXPLODED VIEW PARTS LIST
Ref. No. TPV part no. LGE part no. Description
705GQ9CS027 BEZEL ASSY
010
705GQ9CS026 BEZEL ASSY
020 KEPC8QG2 KEY BOARD
750GLU215H1013N000 PANEL M215HW01 V00 XM AUO
750GLU215H1013M0LG PANEL M215HW01 V000 XM AUO
030
750GLG215W1A13M0LG PANEL LM215WF1-TLA1 GZ LGD
756GQ8CB KL013 MAIN BOARD-CBPCRNDLGQ2
040
756GQ9CB KL002 MAIN BOARD-CBPCRNDLGQ2
050
PWPC8C41LYB1 POWER BOARD
060 Q15G0415201 MAIN FRAME
070
705GQ934047 REAR COVER/HINGE/STAND ASS'Y
080 705GQ9CS028 BASE ASSY
090 089G 728HAA 2G SIGNAL CABLE
100 089G1748HAA AC DVI CABLE
110 095G8018 3D677 LVDS CABLE 30P-30P 160MM
120 089G421A18N IS POWER CORD
