- 29 -
C435 065G040210412T CHIP 0.1UF 16V X7R
C438 065G0805105 12 1UF +-10% 6V X7R
C439 065G060310517T MLCC 0603 CAP 1UF Z 16V Y5V
C440 065G0805475A7Z CAP CHIP 4.7UF 10V Y5V -20%~+80%
C442 065G040210412T CHIP 0.1UF 16V X7R
C446 065G040210412T CHIP 0.1UF 16V X7R
C447 065G040210412T CHIP 0.1UF 16V X7R
C448 065G060310517T MLCC 0603 CAP 1UF Z 16V Y5V
C702 065G040210412T CHIP 0.1UF 16V X7R
C704 067G 2151014PB EC 100UF M 25V 6.3*11MM
C705 065G040210412T CHIP 0.1UF 16V X7R
C707 067G 2151014PB EC 100UF M 25V 6.3*11MM
C708 065G040210412T CHIP 0.1UF 16V X7R
C709 065G040210412T CHIP 0.1UF 16V X7R
DIODE
D102 093G 64 42 PP BAV70 SOT-23
ZD104 093G 39GA01 T RLZ5.6B
IC
U102 056G1133 34 1 IC M24C02-RMN6TP 2KB SO-8
U103 056G 662502 IC ESD AZC199-04S SOT23-6L
U104 056G 662502 IC ESD AZC199-04S SOT23-6L
U105 056G 662502 IC ESD AZC199-04S SOT23-6L
U106 056G 662502 IC ESD AZC199-04S SOT23-6L
U107 056G 662502 IC ESD AZC199-04S SOT23-6L
U401 056G 562583 IC NT68667UFG/C QFP-128L
U402 056G1133 81 SST25LF020A-33-4C-SAE
SMTCR-U402 100GKNAI001N11 MCU ASS'Y-056G1133 81
U703 056G 563 52 IC AP1117D33L-13 TO252-3L DIODES
U704 056G 56327A IC AP1117E18LA SOT223-3L ANACHIP
TRANSISTOR
Q301 057G 763 1 A03401 SOT23 BY AOS(A1)
Q302 057G 417 12 T KEC 2N3904S-RTK/PS
Q401 057G 417 13 T KEC 2N3906S-RTK/PS
Q701 057G 417 12 T KEC 2N3904S-RTK/PS
RESISTOR
R101 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R102 061G0603000 RST CHIP MAX 0R05 1/10W
R103 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R104 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R105 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R106 061G0402222 RST CHIPR 2.2 KOHM +-5% 1/16W
R107 061G0402222 RST CHIPR 2.2 KOHM +-5% 1/16W
R108 061G0402750 RST CHIPR 75 OHM +-5% 1/16W
R109 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R110 061G0402471 RST CHIPR 470 OHM +-5% 1/16W
R111 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R112 061G0402750 RST CHIPR 75 OHM +-5% 1/16W
