LG Flatron W2243T User Manual


- 31 -
R439 061G0402000 RST CHIP MAX 0R05 1/16W
R444 061G0402392 RST CHIP 3.9K 1/16W 5%
R445 061G0402392 RST CHIP 3.9K 1/16W 5%
R446 061G0402000 RST CHIP MAX 0R05 1/16W
R462 061G0402105 RST CHIPR 1MOHM +-5% 1/16W
R465 061G0402222 RST CHIPR 2.2 KOHM +-5% 1/16W
R466 061G0402000 RST CHIP MAX 0R05 1/16W
R468 061G0603101 RST CHIPR 100 OHM +-5% 1/10W
R702 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W
R704 061G0402223 RST CHIPR 22 KOHM +-5% 1/16W
R705 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W
R706 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R708 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W
FB101 071G 59K190 B 19 OHM BEAD
FB102 071G 59K190 B 19 OHM BEAD
FB103 071G 59K190 B 19 OHM BEAD
FB105 071G 59B121 TB160808B
FB301 071G 56K121 CHIP BEAD
FB401 071G 56G301 EA BEAD 300 OHM
FB403 071G 56V301 B CHIP BEAD FCM2012VF-301T07 BULLWILL
FB404 071G 56G301 EA BEAD 300 OHM
FB406 071G 56V301 B CHIP BEAD FCM2012VF-301T07 BULLWILL
FB407 071G 56G301 EA BEAD 300 OHM
OTHER
X401 093G 2251B J NXS12.000AC30F-BT-2
CN101 088G 35315F XH D-SUB 15PIN VERTICAL CONN WITH SCREW
CN102 088G 35424F N DVI 24PIN CONN F WITH SCREW
CN302 033G8027 30 H WAFER 30P 2.0MM RIGHT ANGLE
CN402 033G3802 7B Y CONNECTOR 7P 2.0 DIP
CN701 033G3802 9B Y W WAFER
POWER BOARD
CAPACITOR
C801 065G0805473 32 CHIP 0.047UF 50V X7R
C802 065G0805473 32 CHIP 0.047UF 50V X7R
C803 065G1206104 32 CHIP 0.1UF 25V X7R 1206
C804 067G215S1024LV LOW ESR EC 1000UF 25V M 12.5*20MM
C805 065G0805333 32 CHIP 0.033UF 50V
C806 065G0805225 12 CAP CHIP 0805 2.2UF K 16V X7R
C808 065G0805333 32 CHIP 0.033UF 50V
C809 065G080522131G CAP CHIP 0805 220PF G 50V NPO
C810 065G0603222 32 CHIP 2200PF 50V X7R
C811 065G0805474 32 0.47UF +-10% 50V X7R
C814 065G0603221 31 CER1 0603 NP0 50V 220P P
C815 065G0805474 32 0.47UF +-10% 50V X7R
C817 065G 3J2096ET 2PF 5% SL 3KV
C818 065G080510522K T CAP CHIP 0805 1UF K 25V X7R
C819 065G 3J5606ET CAP CER 56PF J 3KV
