- 7 -
Copyright LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
3. Optical Character
No Item Criteria Remark
1 Viewing Angle Horizontal(R/L) : +75º/-75º(min), +85º/-85º(Typ.)
<CR ≥10> Vertical(Top/Bottom) : +70º/-70º(min), +80º/-80º (Typ.)
2 Luminance Minimum 180(min)
6500K
Luminance(cd/m 2 ) (Full white pattern, 0.70V)
Brightness
Uniformity
75%(min)
3 Contrast Ratio 600(Min), 1000(Min) DFC-> 1,000,000:1(Min)
4 Response Time On/off:5ms(TYP), Gray to Gray: 2ms(TYP)
5 Light Leakage Condition: Do not visible at 300 Lux
4. Engineering Specification
1 Supported Sync. Type Separate Sync., SOG, Digital Remarks
2 Operating Frequency Analog/ Horizontal 30 ~ 83kHz
Digital Vertical 56 ~ 75 Hz
HDMI Horizontal 28 ~ 83kHz
Vertical 48 ~ 61 Hz
3 Resolution Analog/ Max. 1920x1080 @ 60Hz
Digital Recommend 1920x1080 @ 60Hz
HDMI Max. 1920x1080 @ 60Hz
Recommend 1920x1080 @ 60Hz
4 Input Voltage Voltage : 100 – 240 Vac, 50 or 60Hz
5 Inrush Current Cold Start : 50 A Hot : 120 A
Operating Condition Sync(H/V) Video LED Wattage
Test condition
32W (Max)
1. 1920x1080 @ 60Hz
6 On Mode On/On Active RED
28W (typ)
2. burst pattern
3. 100~240V
4. After aging 30min
Off/On
Sleep Mode On/Off Off blinking 1W
Off/Off
Off Mode
- - Off 1W
(Power switch off)
7 MTBF
50,000 HRS with 90% Lamp Life : 50,000 Hours(Min)
Confidence level
8 Using Altitude 5,000 m (for Reliability) 3,000m(for FOS)
Temperature 10 °C ~ 35 °C
9 Environment
0perating
Humidity 10% ~ 80%
Condition
Storage
Temperature -20 °C ~ 60 °C
Humidity 5% ~ 90% non-condensing
