5. LCD Panel Characteristic
(1) Standard Measurement Condition
• Ambient Luminance Level : dark ( < 10 lux)
• Ambient Temperature : Normal Temperature(10 ~ 25ºC)
• warm-up Time : More than 30min (at Full White Pattern)
• Input Signal : VESA 1920X1080+ 60Hz
• Contrast : 70 (But, the contrast is 100 when we check response time)
• Brightness : Max. 100
• 6500K : Color Temperature Setting is 6500 K( if it’s not special specification)
• Clock/Clock Phase : The Best Setting
(2) Another Spec.: Product Specification Standard( LG(55)G1-1034 )
(3) Cosmetic Spec. : LCD Module IIS Spec.
5.1 Display Area
1) Active Display Area of the LCD Monitor Should be within Cabinet’s Bezel.
2) Distance Difference between Active Area and Bezel
| A-B|<1.0 mm , | C-D|<1.0 mm
A: The Distance from The Left of Active Area to the Bezel
B: The Distance from The Right of Active Area to the Bezel
C: The Distance from The Top of Active Area to the Bezel
D: The Distance from The Bottom of Active Area to the Bezel
C
B
D
A
Active Area
Bezel
No Item Content Remark
Maker AUO
Type TFT Color LCD Module
Active Display Area
24 inches (609.7mm)
diagonal (Aspect ratio 16:10)
Pixel Pitch [mm] 0.2767mm x 0.2767mm
1 LCD Module Electrical Interface 2ch-LVDS
Feature
Color Depth
16.7M colors
(RGB 6-bit + Hi_FRC)
Size (Outline) [mm] 556.0(H) x 323.2(V) x 14.55(D) mm
Surface Treatment Anti-Glare, Hard Coating (3H)
Operating Mode
Transmissive mode
Normally White
Back light Unit White LED
R/T Typical Rise Time: 3.4 , Fall Time: 1.6
Max. Rise Time: 7.4 , Fall Time: 2.6
Minimum Normal Maximum
White Wx 0.283
Wy
Typ-0.015
0.298
Typ+0.015 9300K
2 CIE Color White u’ 0.313
Coordinates v’
Typ-0.015
0.329
Typ+0.015
Red Rx 0.635
Ry 0.349 6500K
Green Gx Typ-0.03 0.335 Typ+0.03
Gy 0.607
Blue Bx 0.146
By 0.058
