50
Pin2(BL)
Pin7(SB)
In Crush Mode,
Is the voltage between
pin2 and pin7 of CON4 like
as below, while pushing the
lever switch?
CON4
Is the connection loose?
(Hinge)
Replace
Main PCB
Pushing
Normal
Level switch
Pin2 To Pin7
Pin2 To Pin7
230 V
0 ~2V
Test Point
Result
Is the resistance value
between (1) and (2) of the
Auger motor like as below?
After plug in,
explain to the customer!
Output voltage of auger motor
Replace
Auger Motor
No
Yes
No
Reconnect
Yes
(1) To (2)
Test Point
12.3 ~ 15.1
Ω
Result
Yes
No
Is the connection loose?
Reconnect
Yes
No
(1)
(2)
49
51
