52
Pin2Pin7
Pin8 Pin2
In Crush Mode,
Is the voltage between
pin2 and pin7 of CON3
like as below, while pushing
the lever switch?
CON4
CON4
In Crush Mode,
Is the voltage between
pin2 and pin7 of CON3
like as below, while pushing
the lever switch?
Replace
Main PCB
Pushing
Normal
Level switch
Pin2 To Pin7
Pin2 To Pin7
230 V
0 ~ 2V
Test Point Result
Is the connection loose?
(Hinge)
Is the connection loose?
Is the resistance value
between (1) and (2) of the
Auger motor like as below?
Output voltage of auger motor
Reconnect
Yes
Reconnect
Yes
Replace
Auger Motor
No
No
No
RePlace
Main PCB
No
Pushing
Normal
Level switch
Pin2 To Pin8
Pin2 To Pin8
230 V
0 ~ 2V
Test Point Result
Output voltage of Cube
(1) To (2)
Test Point
12.3 ~ 15.1 Ω
Result
Yes
Yes
(1) (2)
No
Yes
