LG HCED3615S Service Manual

-17-
PARTS OF THE RANGE HOOD
3 LIGHTS BUTTON
• The light has two levels: High and Low.
• From off, press one time for High. Press again for
Low. Press again to power lights off.
• Press and hold the Light button for 3 seconds to
connect to a home Wi-Fi network. See page 8 for
more information.
4 DISPLAY INDICATORS
Mesh Filter Clean Reminder (always enabled)
•
After 30 hours of fan usage, the button indicator
will begin to slowly blink indicating it is time to clean
the mesh filters.
• To reset: With hood off: hold the button for three
seconds. All LED indicators will blink two times
confirming the 30 hour timer has been reset.
Charcoal Filter Replace Indicator
(disabled by
default, must be enabled if recirculating hood)
•
To enable Charcoal Filter Replacement Reminder:
With hood off, hold button and button
simultaneously for two seconds. All LED indicators
will blink two times confirming the Charcoal Filter
Replace Reminder is disabled.
• To disable Charcoal Filter Replacement Reminder:
With hood off, hold button and button
simultaneously for two seconds. All LED indicators
will blink two times confirming the Charcoal Filter
Replace Reminder is disabled.
• After 120 hours of fan usage the button will
slowly blink indicating the charcoal filters need
replacment.
• To reset: With hood off, hold the button for two
seconds. All LED indicators will blink two times
confirming the 120 hour timer has been reset.

LG HCED3615S Specifications

General

Color	stainless steel
Hood Type	wall
Venting Type	convertible
Temperature Sensor	no
Number of Fan Speeds	5
CFM	600 cubic feet per minute
Duct Diameter	6 inches
Filters	2
Sones	1 sones
Control Type	touch pad
Delay Start	yes
Interior Light	yes
Remote Control	no
Wi-Fi	wi-fi
Voltage	120 volts
Current	15 amperes

Weight and Dimensions

Depth	22 1/16 inches
Height	48 1/2 inches
Width	35 7/16 inches
Net Weight	37 pounds
