1. Specifications
3
THERMA V Monobloc
Product Data
Note
1. Due to our policy of innovation, some specifications may be changed without notification.
2. Wiring cable size must comply with the applicable local and national codes. And “Electric characteristics” chapter should be considered for
electrical work and design. Especially the power cable and circuit breaker should be selected in accordance with that.
3. Sound power level is measured in accordance with EN 12102-1 and ISO 9614.
• Rated : This mode is measured on the rated condition in the semi-anechoic rooms. Therefore, these values may vary depending on operation
conditions.
• Daytime max : This mode is measured based on max. fan RPM and max. compressor Hz. that can be reached under outdoor air temperature 2°C.
• Low noise : This mode lowers noise by limiting the compressor Hz. and fan RPM, and thus the performance may be limited.
4. Performances are accordance with EN14511 and reflect ErP testing conditions. The values indicated above are the declared values at rated
conditions acc. ErP regulation. For max. capacities, please refer to Performance Data.
5. This product contains Fluorinated greenhouse gases.
6. SCOP is in accordance with EN14825.
7. Rated running currents are based on the declared values under the following conditions.
•
Heating : Outdoor Temp. 7°CDB / 6°CWB, Leaving Water Temp. 35℃
•
Cooling : Outdoor Temp. 35°C(DB) / 24°C(WB), Leaving Water Temp. 18°C
8. All installation sites must be equipped with an earth leakage circuit breaker (ELCB).
* DHW 65~80°C Operating is available only when the booster heater is operating.
** This is the power input i accordance with the 80% pump capacity setting at rated water flow rate. When the OH SUNG pump is set as 80%
capacity, it’s head is similar to that of the GRUNDFOS pump at rated water flow rate.
Water pump***
Type -
Canned type for hot water
circulation
Canned type for hot water
circulation
Model (maker, name) -
GRUNDFOS, UPML GEO 20-105
CHBL
GRUNDFOS, UPML GEO 20-105
CHBL
Motor type - BLDC BLDC
Steps of pumping performance - Variable speed 10% to 100% Variable speed 10% to 100%
Power input
Min.~Max. W 17~152 17~152
Rated W 145 145
Max. head m 11 11
Water pump 2***
Type -
Canned type for hot water
circulation
Canned type for hot water
circulation
Model (maker, name) - OH SUNG, ODM-061P OH SUNG, ODM-061P
Motor type - BLDC BLDC
Steps of pumping performance - Variable speed 10% to 100% Variable speed 10% to 100%
Power input
Min.~Max. W 17 ~ 152 17 ~ 152
Rated W 145 145
Max. head m 11 11
Heat exchanger
(refrigerant to water)
Type - Brazed plate HEX Brazed plate HEX
No. - 1 1
Number of plate EA 76 76
Water volume ℓ 1 1
Water strainer
Supply type
Loose supply
(externally installed)
Loose supply
(externally installed)
Mesh size 30 30
Max. particle size 0.6 0.6
Material Stainless steel Stainless steel
Safety valve
(water cycle)
Pressure limit Upper limit bar 3.0 3.0
Flow sensor
Type - Vortex Vortex
Model(maker,name) SIKA VVXC9SNBUC00252P SIKA VVXC9SNBUC00252P
Measuring
range
Min. ~ Max. ℓ /min 5 ~ 80 5 ~ 80
Trigger point ℓ /min 10 10
Water pressure sensor
Model (maker, name) - Sensata OFM(2HMP) Sensata OFM(2HMP)
Measuring
range
Min. ~ Max. bar 0 ~ 20 0 ~ 20
Sound pressure level Heating(rated, @5m) dB(A) 27 29
Sound power level Heating
Low noise dB(A) 48 50
Rated dB(A) 49 51
Daytime max. dB(A) 59 60
Water connecting
pipes
Inlet inch Male PT 1" according to ISO 7-1 (tapered pipe threads)
Outlet inch Male PT 1" according to ISO 7-1 (tapered pipe threads)
Dimensions
Net(W x H x D) mm 1,560 x 1,019 x 520 1,560 x 1,019 x 520
Shipping(W x H x D) mm 1,620 x 1,180 x 625 1,620 x 1,180 x 625
Weight
Net kg
181.0 181.0
Shipping kg
199.0 199.0
Exterior
Color of front grille - Dark dawn gray Dark dawn gray
RAL Code of front grille
- RAL 7012 RAL 7012
Technical specifications
FHBW126B0
[HM121HF UB60]
FHBW146B0
[HM141HF UB60]
-
-
-
mm
mesh
In the case of integrated water pump, either water pump or water pump 2 will be applied.
***
