17
THERMA V Monobloc
Product Data
7. Capacity Tables
7.1 Heating Operation
■ Maximum Capacity (Include defrost effect)
FHBW098X0 [HM093HFX UB60]
Note
1. DB : Dry bulb temperature(℃), LWT : Leaving water temperature(℃), LPM : Liter per minute ( ℓ /min)
2. TC : Total capacity(kW), EER: Energy efficiency ratio(kW/kW), COP : Coefficient of performance (kW/kW)
3. Direct interpolation is permissible. Do not extrapolate.
4. Measuring procedure follows EN14511.
• Rated values are based on standard conditions, and it can be found on specifications.
• Above table values may not be matched according to installation condition. Except for rated value, the performance is not guaranteed.
• In accordance with the test standard(or nations), the results may vary.
5. The Shaded areas are not guaranteed continuous operation.
Outdoor
Temp.
[°C DB]
Water flow rate 25.9 LPM Water flow rate 16.2 LPM Water flow rate 12.9 LPM
LWT 30 °C LWT 35 °C LWT 40 °C LWT 45 °C LWT 50 °C LWT 55 °C LWT 60°C LWT 65 °C LWT 70°C LWT 75 °C
TC COP TC COP TC COP TC COP TC COP TC COP TC COP TC COP TC COP TC COP
-25 7.84 2.45 7.56 2.25 7.30 2.04 7.07 1.84 6.86 1.62 6.37 1.33
-20 9.002.798.802.568.632.368.522.158.511.948.271.706.771.42
-15 9.003.179.002.959.002.729.002.509.002.339.002.218.711.787.171.49
-7 9.00 3.78 9.00 3.44 9.00 3.22 9.00 3.02 9.00 2.80 9.00 2.60 9.00 2.29 9.00 2.01 8.99 1.78
-4 9.00 4.00 9.00 3.64 9.00 3.43 9.00 3.19 9.00 2.98 9.00 2.74 9.00 2.47 9.00 2.21 9.00 1.94 8.91 1.77
-2 9.00 4.16 9.00 3.79 9.00 3.56 9.00 3.33 9.00 3.08 9.00 2.84 9.00 2.58 9.00 2.33 9.00 2.07 9.00 1.85
2 9.004.829.003.889.003.949.003.679.003.409.003.099.002.728.081.68 6.84 1.44 6.36 1.34
7 9.005.569.004.909.004.479.004.159.003.809.003.529.002.999.002.13 8.03 1.74 7.67 1.60
10 9.00 6.00 9.00 5.19 9.00 4.81 9.00 4.44 9.00 4.05 9.00 3.64 9.00 3.13 9.00 2.35 9.00 2.05 8.95 1.82
15 9.00 6.59 9.00 5.90 9.00 5.39 9.00 4.92 9.00 4.46 9.00 3.98 9.00 3.51 9.00 2.67 9.00 2.49 9.00 2.25
18 9.00 6.94 9.00 6.28 9.00 5.73 9.00 5.22 9.00 4.71 9.00 4.15 9.00 3.74 9.00 2.90 9.00 2.66 9.00 2.37
20 9.00 7.17 9.00 6.54 9.00 5.95 9.00 5.42 9.00 4.89 9.00 4.36 9.00 3.88 9.00 3.05 9.00 2.78 9.00 2.46
35
9.007.669.006.719.006.119.005.519.004.929.004.329.003.639.003.06
