THERMA V Monobloc
7. Capacity Tables
18
Product Data
FHBW126B0 [HM121HF UB60], FHBW128B0 [HM123HF UB60]
Note
1. DB : Dry bulb temperature(℃), LWT : Leaving water temperature(℃), LPM : Liter per minute ( ℓ /min)
2. TC : Total capacity(kW), EER: Energy efficiency ratio(kW/kW), COP : Coefficient of performance (kW/kW)
3. Direct interpolation is permissible. Do not extrapolate.
4. Measuring procedure follows EN14511.
• Rated values are based on standard conditions, and it can be found on specifications.
• Above table values may not be matched according to installation condition. Except for rated value, the performance is not guaranteed.
• In accordance with the test standard(or nations), the results may vary.
5. The Shaded areas are not guaranteed continuous operation.
Outdoor
Temp.
[°C DB]
Water flow rate 34.5 LPM Water flow rate 21.6 LPM Water flow rate 17.3 LPM
LWT 30 °C LWT 35 °C LWT 40 °C LWT 45 °C LWT 50 °C LWT 55 °C LWT 60°C LWT 65 °C LWT 70°C LWT 75 °C
TC COP TC COP TC COP TC COP TC COP TC COP TC COP TC COP TC COP TC COP
-25 8.36 2.42 8.07 2.23 7.79 2.02 7.54 1.82 7.32 1.60 6.37 1.33
-20 9.602.769.392.539.202.339.092.139.081.928.271.706.771.42
-15 10.84 3.09 10.69 2.88 10.55 2.66 10.55 2.44 10.84 2.27 10.76 2.14 8.71 1.78 7.17 1.49
-7 12.00 3.62 12.00 3.30 12.00 3.08 12.00 2.88 12.00 2.66 12.00 2.48 11.27 2.19 10.00 1.97 8.99 1.78
-4 12.00 3.84 12.00 3.49 12.00 3.29 12.00 3.05 12.00 2.84 12.00 2.60 12.00 2.35 10.88 2.13 9.65 1.91 8.91 1.77
-2 12.00 3.98 12.00 3.63 12.00 3.41 12.00 3.19 12.00 2.95 12.00 2.70 12.00 2.45 11.45 2.22 10.29 2.01 9.32 1.84
2 12.00 4.62 12.00 3.72 12.00 3.78 12.00 3.52 12.00 3.26 12.00 2.95 12.00 2.59 8.08 1.68 6.84 1.44 6.36 1.34
7 12.00 5.32 12.00 4.70 12.00 4.28 12.00 3.97 12.00 3.64 12.00 3.37 12.00 2.86 10.28 2.08 8.34 1.73 7.67 1.60
10 12.00 5.74 12.00 4.97 12.00 4.61 12.00 4.25 12.00 3.88 12.00 3.48 12.00 3.00 11.20 2.28 9.90 2.02 8.95 1.82
15 12.00 6.31 12.00 5.65 12.00 5.16 12.00 4.72 12.00 4.27 12.00 3.81 12.00 3.36 12.00 2.55 12.00 2.37 11.09 2.17
18 12.00 6.65 12.00 6.02 12.00 5.48 12.00 5.00 12.00 4.51 12.00 3.97 12.00 3.58 12.00 2.78 12.00 2.54 11.69 2.26
20 12.00 6.87 12.00 6.26 12.00 5.70 12.00 5.19 12.00 4.68 12.00 4.17 12.00 3.72 12.00 2.93 12.00 2.65 12.00 2.32
35
12.00 7.33 12.00 6.42 12.00 5.85 12.00 5.28 12.00 4.71 12.00 4.14 12.00 3.46 12.00 2.90
