7. Capacity Tables
19
THERMA V Monobloc
Product Data
FHBW146B0 [HM141HF UB60], FHBW148B0 [HM143HF UB60]
Note
1. DB : Dry bulb temperature(℃), LWT : Leaving water temperature(℃), LPM : Liter per minute ( ℓ /min)
2. TC : Total capacity(kW), EER: Energy efficiency ratio(kW/kW), COP : Coefficient of performance (kW/kW)
3. Direct interpolation is permissible. Do not extrapolate.
4. Measuring procedure follows EN14511.
• Rated values are based on standard conditions, and it can be found on specifications.
• Above table values may not be matched according to installation condition. Except for rated value, the performance is not guaranteed.
• In accordance with the test standard(or nations), the results may vary.
5. The Shaded areas are not guaranteed continuous operation.
Outdoor
Temp.
[°C DB]
Water flow rate 40.3 LPM Water flow rate 25.2 LPM Water flow rate 20.1 LPM
LWT 30 °C LWT 35 °C LWT 40 °C LWT 45 °C LWT 50 °C LWT 55 °C LWT 60°C LWT 65 °C LWT 70°C LWT 75 °C
TC COP TC COP TC COP TC COP TC COP TC COP TC COP TC COP TC COP TC COP
-25 8.882.408.572.208.282.008.011.807.781.596.371.33
-20 10.20 2.73 9.97 2.50 9.78 2.31 9.66 2.11 9.48 1.91 8.27 1.70 6.77 1.42
-15 12.06 3.03 11.99 2.82 11.79 2.60 11.59 2.40 11.29 2.25 10.76 2.14 8.71 1.78 7.17 1.49
-7 14.00 3.51 14.00 3.19 13.82 2.99 13.63 2.80 13.45 2.60 12.58 2.45 11.27 2.19 10.00 1.97 8.99 1.78
-4 14.00 3.72 14.00 3.39 13.90 3.20 13.83 2.96 13.83 2.76 13.23 2.55 12.06 2.34 10.88 2.13 9.65 1.91 8.91 1.77
-2 14.00 3.86 14.00 3.52 13.96 3.31 13.95 3.10 14.00 2.85 13.71 2.62 12.59 2.42 11.45 2.22 10.29 2.01 9.32 1.84
2 14.00 4.48 14.00 3.61 14.00 3.67 14.00 3.41 14.00 3.16 14.00 2.86 13.16 2.548.081.686.841.446.361.34
7 14.00 5.16 14.00 4.50 14.00 4.16 14.00 3.85 14.00 3.54 14.00 3.27 14.00 2.78 10.28 2.08 8.34 1.73 7.67 1.60
10 14.00 5.57 14.00 4.82 14.00 4.48 14.00 4.12 14.00 3.76 14.00 3.38 14.00 2.91 11.20 2.28 9.90 2.02 8.95 1.82
15 14.00 6.12 14.00 5.48 14.00 5.01 14.00 4.58 14.00 4.14 14.00 3.70 14.00 3.26 12.72 2.53 12.02 2.37 11.09 2.17
18 14.00 6.45 14.00 5.84 14.00 5.32 14.00 4.85 14.00 4.38 14.00 3.86 14.00 3.47 13.82 2.70 12.89 2.50 11.69 2.26
20 14.00 6.67 14.00 6.08 14.00 5.53 14.00 5.04 14.00 4.54 14.00 4.05 14.00 3.61 14.00 2.84 13.47 2.59 12.09 2.32
35
14.00 7.12 14.00 6.23 14.00 5.68 14.00 5.12 14.00 4.57 14.00 4.01 14.00 3.34 12.80 2.85
