LG HN1639HC NK0 Data Book

27
THERMA V Monobloc
Product Data
9. Sound levels
9.1 Sound Power Level
FHBW098X0 [HM093HFX UB60]
Note
1. Data is valid at diffuse field condition.
2. Reference acoustic intensity 0dB = 10E-6μW/m
2
3. Sound power level is measured on the rated condition in the reverberation rooms. Refer to the Model Specifications for nominal conditions(Power
source and Ambient temperature, etc)
4. Sound levels can be increased in accordance with installation and operating conditions.
5. Sound level will vary depending on a range of factors such as the construction (acoustic absorption coefficient) of particular installed place in
which the equipment in installed.
6. Sound power level is measured in accordance with EN 12102-1 and ISO 9614.
• Rated : This mode is measured on the rated condition in the semi-anechoic rooms. Therefore, these values may vary depending on operation
conditions.
• Daytime max : This mode is measured based on max. fan RPM and max. compressor Hz. that can be reached under outdoor air temperature 2°C.
• Low noise : This mode lowers noise by limiting the compressor Hz. and fan RPM, and thus the performance may be limited.
Model Heating [dB(A)]
Outdoor Unit Indoor Unit Rated Low Noise Daytime Max
FHBW098X0 [HM093HFX UB60] FHNW16809C0 [HN1639HC NK0] 49.0 48.0 59.0
63 125 250 500 1000 2000 4000 8000 Overall [dB(A)]
78.0 67.6 58.1 56.3 51.5 46.0 40.0 32.0 59.0
67.4 55.7 47.1 44.6 44.7 32.1 33.4 35.4 49.0
66.4 54.7 46.1 43.6 43.7 31.1 32.4 34.4 48.0
Octave Band [Hz]
Day Max. [dB]
Rated [dB]
Low noise [dB]
0
10
20
30
40
50
60
70
80
90
100
110
120
63 1 25 250 500 100 0 200 0 4 00 0 8 00 0
Sound Power Level (0dB = 10E-6μW/m
2
)
Octave Band Center Frequency (Hz)
NR-70
NR-65
NR-60
NR-55
NR-50
NR-45
NR-40
NR-35
NR-30
NR-75
NR-25
NR-20
NR-80
NR-85
NR-90
 Day Max.
 Rated
Ǹ Low noise
NR-95
NR-100
NR-105
NR-110
