THERMA V Monobloc
7. Capacity Tables
20
Product Data
FHBW166B0 [HM161HF UB60], FHBW168B0 [HM163HF UB60]
Note
1. DB : Dry bulb temperature(℃), LWT : Leaving water temperature(℃), LPM : Liter per minute ( ℓ /min)
2. TC : Total capacity(kW), EER: Energy efficiency ratio(kW/kW), COP : Coefficient of performance (kW/kW)
3. Direct interpolation is permissible. Do not extrapolate.
4. Measuring procedure follows EN14511.
• Rated values are based on standard conditions, and it can be found on specifications.
• Above table values may not be matched according to installation condition. Except for rated value, the performance is not guaranteed.
• In accordance with the test standard(or nations), the results may vary.
5. The Shaded areas are not guaranteed continuous operation.
Outdoor
Temp.
[°C DB]
Water flow rate 46.0 LPM Water flow rate 28.8 LPM Water flow rate 23.0 LPM
LWT 30 °C LWT 35 °C LWT 40 °C LWT 45 °C LWT 50 °C LWT 55 °C LWT 60°C LWT 65 °C LWT 70°C LWT 75 °C
TC COP TC COP TC COP TC COP TC COP TC COP TC COP TC COP TC COP TC COP
-25 9.41 2.37 9.08 2.18 8.76 1.98 8.48 1.78 7.81 1.59 6.37 1.33
-20 10.80 2.70 10.56 2.48 10.35 2.28 10.23 2.09 9.48 1.91 8.27 1.70 6.77 1.42
-15 13.36 2.96 13.28 2.75 12.74 2.56 12.15 2.38 11.29 2.25 10.76 2.14 8.71 1.78 7.17 1.49
-7 16.00 3.39 16.00 3.09 15.17 2.92 14.35 2.77 13.52 2.59 12.58 2.45 11.27 2.19 10.00 1.97 8.99 1.78
-4 16.00 3.61 16.00 3.28 15.43 3.12 14.85 2.91 14.29 2.74 13.23 2.55 12.06 2.34 10.88 2.13 9.65 1.91 8.91 1.77
-2 16.00 3.75 16.00 3.41 15.69 3.22 15.34 3.03 14.81 2.82 13.71 2.62 12.59 2.42 11.45 2.22 10.29 2.01 9.32 1.84
2 16.00 4.34 16.00 3.50 16.00 3.55 16.00 3.31 16.00 3.06 14.84 2.82 13.16 2.548.081.686.841.446.361.34
7 16.00 5.01 16.00 4.30 16.00 4.03 16.00 3.74 16.00 3.43 16.00 3.17 14.25 2.77 10.28 2.08 8.34 1.73 7.67 1.60
10 16.00 5.41 16.00 4.68 16.00 4.34 16.00 4.00 16.00 3.65 16.00 3.28 14.92 2.87 11.20 2.28 9.90 2.02 8.95 1.82
15 16.00 5.94 16.00 5.32 16.00 4.86 16.00 4.44 16.00 4.02 16.00 3.58 16.00 3.16 12.72 2.53 12.02 2.37 11.09 2.17
18 16.00 6.25 16.00 5.66 16.00 5.16 16.00 4.71 16.00 4.25 16.00 3.74 16.00 3.37 13.82 2.70 12.89 2.50 11.69 2.26
20 16.00 6.47 16.00 5.90 16.00 5.37 16.00 4.88 16.00 4.40 16.00 3.93 16.00 3.50 14.56 2.81 13.47 2.59 12.09 2.32
35
16.00 6.90 16.00 6.05 16.00 5.51 16.00 4.97 16.00 4.43 16.00 3.89 14.40 3.32 12.80 2.85
