FHNW16809C0 [HN1639HC NK0]
Category
Unit Specification
Major Minor
Classification Chassis - K1
Operation range(Leaving Water)
Cooling(min. ~ max.) ℃(DB) 5~27
Heating(min. ~ max.) ℃(DB) 15~75
Domestic hot water(min. ~ max.) ℃(DB) 15 ~ 80*
Power supply Case 1 V, Φ, Hz 220-230-240, 1, 50
Current Current(max.) A 0.6
Recommended circuit breaker(ELCB) - A 10
Connecting cable
Power supply cable(H07RN-F) mm² × cores 0.75 x 3C
Communication cable(H07RN-F) mm² × cores 0.75 x 2C
Electric backup heater
Type - Sheath
Power supply V, Φ, Hz 380-400-415, 3, 50
Number of heating coil EA 3
Capacity combination kW 3.0 + 3.0 + 3.0
Heating steps Step 2
Rated running current A 13
Power cable (H07RN-F) (included earth) mm² × cores 2.5 x 4C
Recommended circuit breaker(ELCB) A 16
Expansion tank
Volume(max.) ℓ 8
Water pressure(max.) bar 3
Water pressure(pre-charged) bar 1
Sound power level Heating(rated) dB(A) 39
Water connecting pipes
Inlet inch
Male PT 1" according to ISO 7-1
(tapered pipe threads)
Outlet inch
Male PT 1" according to ISO 7-1
(tapered pipe threads)
Dimensions
Net(W x H x D) mm 490 x 850 x 315
Shipping(W x H x D) mm 563 x 1082 x 375
Weight
Net kg 31
Shipping kg 36
Exterior
Color - Noble White
RAL code - RAL 9016
Note
■ Due to our policy of innovation, some specifications may be changed without notification.
■ Wiring cable size must comply with the applicable local and national codes. And “Electric characteristics” should be considered for electrical work and design.
Especially the power cable and circuit breaker should be selected in accordance with that.
■ Sound power level is measured on the rated condition in accordance with ISO 9614 standard.
Therefore, these values depend on the ambient conditions and values are normally higher in actual operation.
■ * DHW 65~80°C operating is available only when the booster heater is operating.
Hydro Unit
1. Specifications
Product Data
1-2
