Contents
Main unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Making system connections . . . . . . . . . . . . . . . . . . .6-7
Listening to the sound from your analog component . .7
OSD Initial language settings - optional . . . . . . . . . . . .8
Initial Setting the Area Code . . . . . . . . . . . . . . . . . . . . .8
Adjust the settings . . . . . . . . . . . . . . . . . . . . . . . . . .8-10
Setting the sound mode . . . . . . . . . . . . . . . . . . . . . . .10
Displaying Disc Information . . . . . . . . . . . . . . . . . . . .11
Playing a disc or file . . . . . . . . . . . . . . . . . . . . . . .11-13
Viewing photo files . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Listening to the radio . . . . . . . . . . . . . . . . . . . . . . . . .14
Home Theater Speaker ez Set-up . . . . . . . . . . . . . . .14
Listening to music from your USB device . . . . . . . . .15
Recording music from CD to your USB device . . . . .16
Listening to music from your portable player . . . . . . .16
Listening to music from your iPod . . . . . . . . . . . . . . .17
Language Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Area Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Types of Playable Discs . . . . . . . . . . . . . . . . . . . . . . .20
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
What is SIMPLINK?
Some functions of this unit are controlled by TV’s remote control when this unit and
LG TV with SIMPLINK are connected through HDMI connection.
• Controllable functions by LG TV’s remote control; Play, Pause, Scan, Skip, Stop,
Power Off, etc.
• Refer to the TV owner’s manual for the details of SIMPLINK function.
• LG TV with SIMPLINK function has the logo as shown above.
• Use a higher version cable than 1.2A HDMI cable.
iPod is a trademark of Apple Inc., registered in the U.S.
and other countries.
Welcome to your new
stylish home theater system
POWER: This unit operates on a mains supply of 200-240V~, 50/60Hz.
WIRING: This unit is supplied with a BSI 1363 approved 13 amp mains plug, fused
at 5 amp. When replacing the fuse always use a 5 amp BS 1362, BSI or ASTA
approved type. Never use this plug with the fuse cover omitted. To obtain a
replacement fuse cover contact your dealer. If the type of plug supplied is not
suitable for the mains sockets in your home, then the plug should be removed and
a suitable type fitted. Please refer to the wiring instructions below:
WARNING: A mains plug removed from the mains lead of this unit must be
destroyed. A mains plug with bared wires is hazardous if inserted in a mains
socket. Do not connect either wire to the earth pin, marked with the letter E or with
the earth symbol or coloured green or green and yellow.
If any other plug is fitted, use a 5 amp fuse, either in the plug, or at the
distribution board.
IMPORTANT: The wires in this mains lead are coloured in accordance with the
following codes:
- BLUE: NEUTRAL, BROWN: LIVE - As the colours of the wires in the mains lead
of this unit may not correspond with the coloured marking identifying the terminals
in your plug, proceed as follows: The wire which is coloured blue must be
connected to the terminal which is marked with the letter N or coloured black. The
wire which is coloured brown must be connected to the terminal which is marked
with the letter L or coloured red.
