27
REFERENCE
❋ Designs and specifications are subject to change without notice.
GeneralCD/DVD
Amplifier
Speakers
Tuner
FM
AM
[MW]
Specifications
Video
Power supply Refer to main label
Power consumption Refer to main label
Net Weight 2.4 kg
External dimensions (W x H x D) 360 x 63 x 307 mm
Operating conditions Temperature: 5°C to 35°C, Operation status: Horizontal
Operating humidity 5% to 85%
Laser Semiconductor laser, wavelength 650 nm
Signal system PAL 625/50, NTSC 525/60
Frequency response (audio) 160 Hz to 18 kHz
Signal-to-noise ratio (audio) More than 75 dB (1 kHz, NOP -6 dB, 20 kHz LPF/A-Filter)
Dynamic range (audio) More than 70 dB
Harmonic distortion (audio) 0.5 % (1 kHz, at 1W position) (20 kHz LPF)
Video output 1.0 V (p-p), 75 Ω, negative sync./ SCART (TO TV)
COMPONENT VIDEO OUT (Y) 1.0 V (p-p), 75 ohms, negative sync, RCA jack x 1
(P
B)/(PR) 0.7 V (p-p), 75 ohms, RCA jack x 1
Tuning Range 87.5 - 108.0 MHz or 65.0 - 74.0 MHz, 87.5 - 108.0 MHz
Intermediate Frequency 10.7 MHz
Signal-to Noise Ratio 60 dB (Mono)
Frequency Response 160 - 10,000 Hz
Tuning Range 522 - 1,620 kHz or 520 - 1,720 kHz
Intermediate Frequency 450 kHz
Stereo mode 45W + 45W (Rated Output Power 30W, 4Ω at 1 kHz, THD 10 %)
Surround mode Front: 45W + 45W (Rated Output Power 30W, THD 10 %)
Centre*: 45W
Surround*: 45W + 45W (Rated Output Power 30W, 4Ω at 1 kHz, THD 10 %)
Subwoofer*: 75W (Rated Output Power 60W, 8Ω at 30 Hz, THD 10 %)
Inputs AUX IN
Front/Rear/Center Speaker Passive Subwoofer
(SH32ST-S) (SH32ST-W)
Type 1 Way 1 Speaker 1 Way 1 Speaker
Impedance 4 Ω 8 Ω
Frequency Response 160 - 20,000 Hz 65 - 1,500 Hz
Sound Pressure Level 82 dB/W (1m) 80 dB/W (1m)
Rated Input Power 45 W 75 W
Max. Input Power 90 W 150 W
Net Dimensions (W x H x D) 98 x 101 x 105 mm 181 x 351 x 278 mm
Net Weight 0.52kg 3.4kg
Wireless Transmitter (W92-T) Transmission Output 2.4GHz
Power Supply DC 7V
Wireless Receiver (W92-R) Power supply Refer to label of wireless Receiver
Power consumption Refer to label of wireless Receiver
Reception Output 2.4GHz
(*
Depending on the sound mode
settings and the source, there
may be no sound output.)
Wireless
system
