"PROTECTION" appears on the FLD.
Power on.
Replace TI AMP IC(IC701~704).
"PROTECTION"
appears continuously on the FLD.
Is the IC101 pin64
"LOW" signal(0V)?
Is the Q703, Q704 and 705 normal?
After unplug power cord, connect again.
OK.
Replace IC101.
Replace the Q703, Q704 and Q705.
No
No
No
Yes
Yes
Yes
Copyright © 2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
To Next Page
