10
Speaker System Connection (SH52TH-S/C/W)
Connect the speakers using the supplied speaker cables.
To obtain the best possible surround sound, adjust the speaker parameters (volume, distance, etc.).
Notes:
Be sure to match the speaker cable to the appropriate terminal on the components: + to + and – to –. If the
cables are reversed, the sound will be distorted and will lack bass.
If you use front speakers with low maximum input rating, adjust the volume carefully to avoid excessive
output on the speakers.
Front speaker
(Right)
Front speaker
(Left)
Rear speaker
(Right surround)
Rear speaker
(Left surround)
Center speaker
Subwoofer
To Next Page
