10. EXPLODED VIEW & REPLACEMENT PART LIST
- 218 -
Level
Location
No.
Description Part Number Specification Color Remark
6 R713 RES,CHIP,MAKER ERHZ0000466 33 Kohm,1/16W ,J ,1005 ,R/TP
6 R714 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
6 R900 RES,CHIP,MAKER ERHZ0000493 51 Kohm,1/16W ,J ,1005 ,R/TP
6 R901 RES,CHIP,MAKER ERHZ0000493 51 Kohm,1/16W ,J ,1005 ,R/TP
6 R902 RES,CHIP,MAKER ERHZ0000493 51 Kohm,1/16W ,J ,1005 ,R/TP
6 R903 RES,CHIP ERHY0003301 100 ohm,1/16W ,J ,1005 ,R/TP
6 R904 RES,CHIP ERHY0003301 100 ohm,1/16W ,J ,1005 ,R/TP
6 R905 RES,CHIP ERHY0003301 100 ohm,1/16W ,J ,1005 ,R/TP
6 R906 RES,CHIP ERHY0003301 100 ohm,1/16W ,J ,1005 ,R/TP
6 R910 RES,CHIP,MAKER ERHZ0000504 68 ohm,1/16W ,J ,1005 ,R/TP
6 R911 RES,CHIP,MAKER ERHZ0000504 68 ohm,1/16W ,J ,1005 ,R/TP
6 R912 RES,CHIP,MAKER ERHZ0000504 68 ohm,1/16W ,J ,1005 ,R/TP
6 R914 RES,CHIP,MAKER ERHZ0000504 68 ohm,1/16W ,J ,1005 ,R/TP
6 R915 RES,CHIP,MAKER ERHZ0000504 68 ohm,1/16W ,J ,1005 ,R/TP
6 R916 RES,CHIP,MAKER ERHZ0000504 68 ohm,1/16W ,J ,1005 ,R/TP
6 R917 RES,CHIP,MAKER ERHZ0000504 68 ohm,1/16W ,J ,1005 ,R/TP
6 R918 RES,CHIP,MAKER ERHZ0000504 68 ohm,1/16W ,J ,1005 ,R/TP
6 R919 RES,CHIP,MAKER ERHZ0000504 68 ohm,1/16W ,J ,1005 ,R/TP
6 R920 RES,CHIP,MAKER ERHZ0000504 68 ohm,1/16W ,J ,1005 ,R/TP
6 R923 RES,CHIP,MAKER ERHZ0000500 62 ohm,1/16W ,J ,1005 ,R/TP
6 R925 RES,CHIP,MAKER ERHZ0000486 47 Kohm,1/16W ,J ,1005 ,R/TP
6 R926 RES,CHIP,MAKER ERHZ0000401 0 ohm,1/16W ,J ,1005 ,R/TP
6 SPFY00 PCB,MAIN SPFY0133301 FR-4 ,0.8 mm,STAGGERED-10 ,KU950,MAIN,PCB
6 U100 IC EUSY0203802
QFN ,56 PIN,R/TP ,GSM/WCDMA TRANSMITTER &
GSM RECEIVER
6 U101 PAM SMPY0008301
35 dBm,53 %,0.0000025 A, dBc,50 dB,6.0*6.0*1.2 ,SMD
,FOR QUAD BAND GSM AND GPRS
6 U102 VCO EXSC0009201
MHz, PPM, pF,SMD ,5.5*4.8*1.5 ,824MHz ~ 915MHz,
1710MHz ~ 1910MHz, 14pin
6 U103 PAM SMPY0012701 28 dBm, %, A, dBc, dB,4*4*1.2 ,SMD ,
6 U104 IC EUSY0084701 SSOP5-P-A ,6 PIN,R/TP ,Inverter, Pb Free
6 U105
COUPLER,RF
DIRECTIONAL
SCDY0003402
-20 dB,-0.25 dB,-35 dB,1.0*0.58*0.35 ,SMD ,1850M ~
1910M, 4pin, Pb Free
6 U106 IC EUSY0280501 , PIN,R/TP ,
6 U202 IC EUSY0232807 sot 23-5 ,5 PIN,R/TP ,1.8V,150mA LDO
6 U203 IC EUSY0064501
SOT-23-5 ,5 PIN,R/TP ,2.7V LDO
REGULATOR,PBFREE
6 U205 IC EUSY0293601 SOT23-5 ,5 PIN,R/TP ,300mA 1.2V LDO Pb-Free
6 U206 IC EUSY0293501 SOT23-5 ,5 PIN,R/TP ,150mA, 2.7V, LDO, Pb-Free
