10. EXPLODED VIEW & REPLACEMENT PART LIST
- 219 -
Level
Location
No.
Description Part Number Specification Color Remark
6 U601 IC EUSY0077701
SC70-5 ,5 PIN,R/TP ,1.8V Low Voltage Comparator with
Rail-to-Rail Input, Pb Free
6 U602 IC EUSY0271201 TQFN ,16 PIN,R/TP ,Quad Analog switch, Pb Free
6 U700 IC EUSY0232808 SOT 23-5 ,5 PIN,R/TP ,3.0V,150mA LDO
6 U701 IC EUSY0186201 32-Pin QFN(5x5) ,32 PIN,R/TP ,Stereo CODEC
6 U702 IC EUSY0196101 BUMP MICRO SMD ,9 PIN,R/TP ,1W AUDIO AMP
6 U703 IC EUSY0303901
QFN,130mW Capless Stereo Headphone Driver ,16
PIN,R/TP ,Capless hp amp
6 U901 IC EUSY0129503 2x2 mm MLPD ,3 PIN,R/TP ,Hall Effect Switch, Pb Free
6 VA600 VARISTOR SEVY0004001 18 V, ,SMD ,3pF, 1005
6 VA601 VARISTOR SEVY0004001 18 V, ,SMD ,3pF, 1005
6 VA602 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA603 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA604 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA605 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA606 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA607 DIODE,TVS EDTY0008606 DFN-2 ,7.82 V,150 mW,R/TP ,PB-FREE
6 VA608 DIODE,TVS EDTY0008606 DFN-2 ,7.82 V,150 mW,R/TP ,PB-FREE
6 VA900 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA901 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA902 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA903 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA904 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA905 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA906 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA907 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
6 VA908 VARISTOR SEVY0000702 14 V,10% ,SMD ,
5 WSYY00 SOFTWARE WSYY0468901
KU950_V10b-NOV-10-2006-VDF-IT+3-PRODUCT-SEC-
BIN
3 SVCY00 CAMERA SVCY0009501 CMOS ,VGA ,Omnnivision 1/6" 44
