2-17
8. AUX ERROR CORRECTION FLOW CHART
AUX no sound?
OK
Something wrong With the AUX?
YES
LCS Series :
JK903, IC802(7, 9),
CN901(15, 17, 19),
PN901(3, 4, 5)
LCF Series :
JK903, IC802(7, 9),
CN971(20, 21, 22),
PN902(20, 21, 22)
NO
Checked the AUX
Signal input?
YES
See the Sound Error correction Process.
NO
Checked the
E-VR & Power AMP?
YES
25
27
Table of Contents
Default Chapter
2
Table of Contents
2
Section 1 Summary
3
Servicing Precautions
3
Esd Precautions
4
Specifications
5
Location of Users Controls
6
Firmware Upgrade Method
7
How to Connect Audio Set to Power Supply
8
Section 2 Electrical
10
Electrical Troubleshooting Guide & Waveforms
10
System Control Error Correction Flow Chart
10
Sound Error Correction Flow Chart
13
Display Error Correction Flow Chart
16
Tuner Error Correction Flow Chart
19
Cdp Error Correction Flow Chart
20
Usb Error Correction Flow Chart
23
Bluetooth Error Correction Flow Chart (Optional)
25
Aux Error Correction Flow Chart
26
Waveforms
27
Circuit Voltage Chart
29
INTERNAL BLOCK DIAGRAM of Ics
32
Ic301 (Ha13173Ah)
32
Ic801 (Tb2946Hq)
34
Ic802 (Bd3702Fv)
35
Ic901 (Mc5502)
36
Wiring Diagram
38
Block Diagram
39
Circuit Diagrams
40
Main Circuit Diagram
40
Front Circuit Diagram
41
Cdp Circuit Diagram
42
Printed Circuit Board Diagrams
43
Main P.C.board
43
Front P.C.board
44
Cdp P.C.board
45
Exploded Views
46
Cabinet and Main Frame Section
46
Mechanism(Pick-Up) Section
47
