2-30
2-29
WIRING DIAGRAM
MAIN BOARD
FRONT BOARD
CD BOARD
24PIN
PN901
24PIN
CN901
30PIN
CN402
30PIN
CN520
ANT
LINE OUT
4CH
SK101
JK601
POWER
HARNESS
CN302
B+, ACC,
Phone Mute,
Dimmer,
Speaker Out,
Power Ant
8PIN
CN301
8PIN
CN599
MICOM <-> DSP
USB /
Tuner Signal
17PIN
CN519
Pick Up
11PIN
CN506
Motor
External
AMP
LCS SERIES:1LINE LCD (VA TYPE)
LCF SERIES:3LINE LCD (VA TYPE)
3PIN
CN405
Wired
Remocon
37
39
Table of Contents
Default Chapter
2
Table of Contents
2
Section 1 Summary
3
Servicing Precautions
3
Esd Precautions
4
Specifications
5
Location of Users Controls
6
Firmware Upgrade Method
7
How to Connect Audio Set to Power Supply
8
Section 2 Electrical
10
Electrical Troubleshooting Guide & Waveforms
10
System Control Error Correction Flow Chart
10
Sound Error Correction Flow Chart
13
Display Error Correction Flow Chart
16
Tuner Error Correction Flow Chart
19
Cdp Error Correction Flow Chart
20
Usb Error Correction Flow Chart
23
Bluetooth Error Correction Flow Chart (Optional)
25
Aux Error Correction Flow Chart
26
Waveforms
27
Circuit Voltage Chart
29
INTERNAL BLOCK DIAGRAM of Ics
32
Ic301 (Ha13173Ah)
32
Ic801 (Tb2946Hq)
34
Ic802 (Bd3702Fv)
35
Ic901 (Mc5502)
36
Wiring Diagram
38
Block Diagram
39
Circuit Diagrams
40
Main Circuit Diagram
40
Front Circuit Diagram
41
Cdp Circuit Diagram
42
Printed Circuit Board Diagrams
43
Main P.C.board
43
Front P.C.board
44
Cdp P.C.board
45
Exploded Views
46
Cabinet and Main Frame Section
46
Mechanism(Pick-Up) Section
47
