13. EXPLODED VIEW & REPLACEMENT PART LIST
- 181 -
Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Note: This Chapterisused for reference, Part order is ordered
by SBOM standard on GCSC
Level LocationNo. Description PartNumber Spec Remark
4 EAJ00 LCD,Module-TFT EAJ62449801
TM030HDH01 QVGA 3.0INCH 240X320 300CD
COLOR 50% 16/9 Typ.500:1, Min.300:1 60Hz
Inverter N LED 2D - Shanghai Tianma Micro-
Electronics Co., Ltd.
4 EBD00
Touch Window
Assembly
EBD61585701
LT300YF2AK CAPACITIVE TOUCH PFF Melfas
MMS128S 3.0" Contact Pad Type - TOVIS
4 EAU00 Motor,DC EAU62043901
DM-YK405-1 3V 125mA 0A 11KRPM 12RPM
40mSEC 0GF.CM 21OHM DONGYANG CHENGJI
CO.
4 EAB00
Speaker,Dual
Mode
EAB62871801
EMS1910TPB1P Nd-Fe-B 700mW 8OHM 91DB
850HZ 1810 3t spring, front side SPRING EM-
TECH
4 EAA00
PIFA
Antenna,Multiple
EAA63027801
LS01-I-13008-A0 MULTI -4DB 4 SIMA - Main
Carrier LS Mtron Ltd.
5 EAA030100
PIFA Antenna
Bluetooth
EAA63027601
LS01-I-13010-A0 SINGLE -4DB 4 SUS - WLAN+BT
Carrier LS Mtron Ltd.
5 EAA030101 PIFA Antenna,GPS EAA63027701
LS01-I-13009-A0 SINGLE -4DB 4 SUS - GPS
Carrier LS Mtron Ltd.
13.2 Replacement Parts
<Main component>
3 EBR00
PCB
Assembly,Main
EBR77751301 LGE410.AAREBK 1.0 Main
4 EBR071800
PCB Assembly
Main,SMT
EBR77751401 LGE410.AAREBK 1.0 Main
5 SAD010000 Software,Mobile SAD33837701
Android JellyBean Base V10a - MIDDLE EAST AND
AFRICA QCT -
5 EBR071600
PCB Assembly
Main,SMT Bottom
EBR77471701 LGE410.ACISBK 1.0 Main
6 FL1008 Filter,Saw EAM62811101
SFH897AQ102 897.5MHz 1.4x1.1x0.6t SMD R/TP
5P WISOL.CO.,LTD
6 C1127
Capacitor(High
Frequency)
Ceramic,Chip
EAE62882701
GRM1555C1H1R2C_H 1.2pF 0.25PF 50V C0G -
55TO+125C 1005 R/TP 0.5+/-0.05 L:1.0+-0.05
W:0.5+-0.05 T:0.5+-0.05 MURATA
MANUFACTURING CO.,LTD.
To Next Page
