13. EXPLODED VIEW & REPLACEMENT PART LIST
- 182 -
Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6
L1029
L1031
Inductor
Multilayer,Chip
ELCH0001049
1005GC2T6N8JLF 6.8NH 5% - 250mA 0.32OHM
3GHZ 8 SHIELD NONE 1.0X0.5X0.5MM R/TP
PILKOR ELECTRONICS LTD.
6 C4073
Capacitor
TA,Conformal
EAE62287901
251M1002107MR12A168 100uF 20% 10V 50UA -
55TO+125C 0.6OHM 3.2X1.6X1.1MM NONE SMD
R/TP 1.2T max. MATSUO ELECTRIC CO.,LTD
6
C1112
L1016
Capacitor
Ceramic,Chip
ECZH0001002
C1005CH1H0R5BT000F 0.5pF 0.1PF 50V NP0 -
55TO+125C 1005 R/TP - TDK KOREA
COOPERATION
6 L1019
Capacitor
Ceramic,Chip
ECZH0000846
C1005C0G1H8R2CT000F 8.2pF 0.25PF 50V NP0 -
55TO+125C 1005 R/TP - TDK KOREA
COOPERATION
6 C4031
Capacitor
Ceramic,Chip
ECZH0000803
C1005C0G1H020CT000F 2pF 0.25PF 50V NP0 -
55TO+125C 1005 R/TP - TDK KOREA
COOPERATION
6 C4032
Capacitor
Ceramic,Chip
ECZH0000802
C1005C0G1H010CT 1pF 0.25PF 50V NP0 -
55TO+125C 1005 R/TP - TDK KOREA
COOPERATION
6 L1022
Capacitor
Ceramic,Chip
ECCH0000180
GRM1555C1H3R3C 3.3pF 0.25PF 50V NP0 -
55TO+125C 1005 R/TP - MURATA
MANUFACTURING CO.,LTD.
6 X4000 Crystal EAW61843401
Q13FC1350000200 32.768KHZ 20PPM
0.000000000007F NONE SMD R/TP EPSON
TOYOCOM CORP
6 FL1003 Filter,Saw SFSY0035001
B9411 2140 1.4*1.1*0.45 SMD R/TP - EPCOS PTE
LTD.
6 U1003 IC,Power Amplifier EAN62733701
SKY77768 3.2V to 4.35V 0 0 0W 0W 0 1 SMD R/TP
10P 3*3, GPIO, SkyHi, Band8 SKYWORKS
SOLUTIONS INC.
6 U1002 IC,Power Amplifier EAN62687101
SKY77761 3.0V to 4.5V 0 0 0W 0W 0 1 SMD R/TP
10P 3*3size, GPIO, Band1, Skyhi SKYWORKS
SOLUTIONS INC.
6 FL1004 Filter,Saw EAM62811001
SFDG50AQ102 1950MHz 1.4x1.1x0.6t SMD R/TP
5P WISOL.CO.,LTD
6 FL1006 Filter,Duplexer EAM62711201
SAYRF1G95GC0F0A 2140 MHz 2112.4 to 2167.6
MHz 1950 MHz 1922.4 to 1977.6 MHz 1.7 typ / 2.1
max 1.2 typ / 1.7 max 2.0x1.6x0.6t DUAL SMD
R/TP 9P MURATA MANUFACTURING CO.,LTD.
