13. EXPLODED VIEW & REPLACEMENT PART LIST
- 191 -
Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6
R1023
R4021
R4023
Resistor,Chip ERHZ0000348
MCR01MZP5F12R0 12OHM 1% 1/16W 1005 R/TP
- ROHM.
6
C3005
C3010
C3016
C3021
C3022
C4040
C4041
C4045
C4046
C4047
C4048
C4069
C4070
C5002
C5003
C9033
C9041
Capacitor
Ceramic,Chip
ECCH0000198
CL05A225MQ5NSNC 2.2uF 20% 6.3V X5R -
55TO+85C 1005 R/TP . SAMSUNG ELECTRO-
MECHANICS CO., LTD.
6
C1038
C4011
Capacitor
Ceramic,Chip
ECCH0007803
CL10A106MP8NNNC 10uF 20% 10V X5R -
55TO+85C 1608 R/TP 0.8MM SAMSUNG
ELECTRO-MECHANICS CO., LTD.
6
C2003
C2010
C2012
C4007
C4022
C4023
C4067
Capacitor
Ceramic,Chip
ECZH0001215
C1005X5R1A105KT000F 1uF 10% 10V X5R -
55TO+85C 1005 R/TP - TDK KOREA
COOPERATION
C 06
C7001
C7023
6
C1018
C1054
C7022
L1039
Capacitor
Ceramic,Chip
ECZH0000830
C1005C0G1H330JT000F 33pF 5% 50V NP0 -
55TO+125C 1005 R/TP - TDK KOREA
COOPERATION
6 U1000
IC,RF
Transceiver,3G
EAN62090401
RTR6285A GSM/EDGE/3G Quad with MSM7227A
CSP R/TP 137P QUALCOMM INCORPORATED.
6 R4013 Resistor,Chip ERHZ0000222
MCR01MZP5F1503 150KOHM 1% 1/16W 1005
R/TP - ROHM.
6
R8009
R8011
R8012
Resistor,Chip ERHZ0000285
MCR01MZP5F4700 470OHM 1% 1/16W 1005 R/TP
- ROHM.
