13. EXPLODED VIEW & REPLACEMENT PART LIST
- 192 -
Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6 R3010 Resistor,Chip ERHZ0000249
MCR01MZP5F22R0 22OHM 1% 1/16W 1005 R/TP
- ROHM.
6
C1076
C1098
Inductor
Multilayer,Chip
ELCH0004703
1005GC2T1N0SLF 1NH 0.3NH - 300mA 0.12OHM
10GHZ 8 SHIELD NONE 1.0X0.5X0.5MM R/TP
PILKOR ELECTRONICS LTD.
6 C9048
Capacitor
Ceramic,Chip
ECZH0025920
GRM033R71C102K 1nF 10% 16V X7R -
55TO+125C 0603 R/TP - - MURATA
MANUFACTURING CO.,LTD.
6 R4009 Resistor,Chip ERHZ0000295
MCR01MZP5F5102 51KOHM 1% 1/16W 1005
R/TP - ROHM.
6 C1105
Capacitor
Ceramic,Chip
ECCH0000113
MCH155A180J 18pF 5% 50V NP0 -55TO+125C
1005 R/TP - ROHM Semiconductor KOREA
CORPORATION
6
L4002
L4003
Inductor,Wire
Wound,Chip
ELCP0008013
MIPSZ2012D2R2 2.2UH 30% - 700mA 0.77 0.7
0.23OHM - - SHIELD 2.0X1.2X1.0 MM NONE R/TP
FDK CORPORATION.
6 R4004 Resistor,Chip ERHZ0000444
MCR01MZP5J223 22KOHM 5% 1/16W 1005 R/TP
- ROHM.
6
L1040
L1041
Inductor
Multilayer,Chip
ELCH0001041
HK1005 10NJ-T 10NH 5% - 250mA 0.31OHM
3.2GHZ 8 SHIELD NONE 1.0X0.5X0.5MM R/TP
TAIYO YUDEN CO.,LTD
6
L1001
L1005
L1008
Inductor
Multila
y
er
,
Chi
p
ELCH0001031
HK1005 15NJ-T 15NH 5% - 300mA 0.46OHM
2.3GHZ 8 SHIELD NONE 1.0X0.5X0.5MM R/TP
TAIYO YUDEN CO LTD
L1008
y , p
TAIYO YUDEN CO
.,
LTD
6 C1053
Capacitor
Ceramic,Chip
ECCH0005604
GRM188R60J106M 10000000
pF,6.3V,M,X5R,TC,1608,R/TP,0.8 mm MURATA
MANUFACTURING CO.,LTD.
6
FB4000
FB4001
Filter,Bead EAM62070801
BLM15EG221SN1D 220 ohm 1.0X0.5X0.5 25%
0.28 ohm 0.7A SMD R/TP 2P 0 MURATA
MANUFACTURING CO.,LTD.
6 ZD4002 Diode,TVS EAH61872501
PESD5V0S1UA 5V 6.2V min. 9.8V 47A 360mW
SOD323 R/TP 2P 1 NXP Semiconductors
6
R6000
R6001
R6002
R6003
R6004
Resistor,Chip ERHY0000254
MCR01MZP5J472 4.7KOHM 5% 1/16W 1005 R/TP
- ROHM.
