13. EXPLODED VIEW & REPLACEMENT PART LIST
- 193 -
Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6 R501 Resistor,Chip ERHZ0000404
MCR01MZP5J102 1KOHM 5% 1/16W 1005 R/TP -
ROHM.
6
C5004
C9019
C9020
C9028
Capacitor
Ceramic,Chip
ECCH0017601
CL05A475MQ5NRNC 4.7uF 20% 6.3V X5R -
55TO+85C 1005 R/TP 0.5MM SAMSUNG
ELECTRO-MECHANICS CO., LTD.
6
C4042
C4062
Capacitor
Ceramic,Chip
ECZH0001102
C1005X7R1C183KT000F 18nF 10% 16V X7R -
55TO+125C 1005 R/TP - TDK KOREA
COOPERATION
6 L9010
Inductor
Multilayer,Chip
ELCH0001035
HK1005 4N7S-T 4.7NH 0.3NH - 300mA 0.21OHM
4GHZ 8 SHIELD NONE 1.0X0.5X0.5MM R/TP
TAIYO YUDEN CO.,LTD
6
R9001
R9002
Resistor,Chip ERHZ0000243
MCR01MZP5F2201 2.2KOHM 1% 1/16W 1005
R/TP - ROHM.
6 C1131 Resistor,Chip ERHZ0000270
MCR01MZP5F33R0 33OHM 1% 1/16W 1005 R/TP
- ROHM.
6 L1027
Inductor
Multilayer,Chip
ELCH0004727
1005GC2TR10JLF 100NH 5% - 100mA 2.3OHM
600MHZ 8 SHIELD NONE 1.0X0.5X0.5MM R/TP
PILKOR ELECTRONICS LTD.
6 L1004
Inductor
Multilayer,Chip
ELCH0001406
LL1005-FHL4N7S 4.7NH 0.3NH - 300mA 0.2OHM
7GHZ 9 SHIELD NONE 1.0X0.5X0.5MM R/TP
TOKO, INC.
6
X2000
Osc
ill
ato
r
EAW61543601
X1G003581002700 19.2MHZ 2PPM 2.8V
2 5 2 0 0 8MM SMD R/TP EPSON TOYOCOM
6
X2000
Oscillator
VCTCXO
EAW61543601
2
.
5
x
2
.
0
x
0
.
8MM
;
SMD R/TP EPSON TOYOCOM
CORP
6
R2000
R4017
Resistor,Chip ERHZ0000493
MCR01MZP5J513 51KOHM 5% 1/16W 1005 R/TP
- ROHM.
6 C4002
Capacitor
Ceramic,Chip
ECZH0003503
GRM188R61E105K 1uF 10% 25V X5R -55TO+85C
1608 R/TP - MURATA MANUFACTURING
CO.,LTD.
6
L4000
L4001
Inductor,Wire
Wound,Chip
ELCP0009409
LQM2HPN2R2MG0L 2.2UH 20% - 1.3A - -
0.08OHM - - SHIELD 2.5X2X1MM NONE R/TP
MURATA MANUFACTURING CO.,LTD.
6 R1021 Resistor,Chip ERHZ0000410
MCR01MZP5J120 12OHM 5% 1/16W 1005 R/TP -
ROHM.
