13. EXPLODED VIEW & REPLACEMENT PART LIST
- 194 -
Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6 U2000
IC,Digital
Baseband
Processor,3G
EAN62405911
MSM7225A-0-AB
576NSP,11x11,ARMv7(1GHz),HSDPA(DPA7.2,UP
A5.76), HVGA LCD, VGA30fps,5MP,MIPI CSI_DSI
NSP R/TP 576P QUALCOMM INCORPORATED.
6 U9001 IC,WiFi EAN62416201
WCN1314-0-87WLNSP-TR-0D WCN1314 Revision
version, WiFi(11bgn) signle band, 3.95x4.16x0.63,
0.4pitch, 65nm, WLCSP R/TP 87P QUALCOMM
INCORPORATED.
6
R2003
R7007
R7008
Resistor,Chip ERHY0003301
MCR01MZP5J101 100OHM 5% 1/16W 1005 R/TP -
ROHM.
6 R2012 Resistor,Chip ERHY0035301
RC1005F4021CS 4.02KOHM 1% 1/16W 1005 R/TP
- SAMSUNG ELECTRO-MECHANICS CO., LTD.
6 CN4001
Connector
Terminal Block
EAG63510501
3.2.02.0218 3P 2.50MM STRAIGHT DIP T/REEL -
SHENZHEN EVERWIN PRECISION
TECHNOLOGY CO.,LTD.
6 U1004 IC,RF Amplifier EUSY0400201
ALM-2506 ,6,R/TP,ALM-1106 GPS LNA H/F
version,IC,GPSIC,GPS AVAGO TECHNOLOGIES
INTERNATIONAL SALES PTE. LIMITED
6 L1012
Inductor,Multilayer,
Chip
ELCH0004706
1005GC2T10NJLF 10NH 5% - 250mA 0.42OHM
2.5GHZ 8 SHIELD NONE 1.0X0.5X0.5MM R/TP
PILKOR ELECTRONICS LTD.
6
C7026
C9030
Capacitor
Ceramic,Chip
ECZH0001121
C1005X7R1H471KT000F 470pF 10% 50V X7R -
55TO+125C 1005 R/TP - TDK KOREA
COOPERATION
6 C2018
Capacitor
Ceramic,Chip
ECCH0010501
GRM1555C1H7R5D 7.5pF 0.5PF 50V C0G -
55TO+125C 1005 R/TP - - MURATA
MANUFACTURING CO.,LTD.
6
C1028
C1040
Inductor
Multilayer,Chip
ELCH0003817
LQG15HS7N5J02D 7.5NH 5% - 300mA 0.24OHM
4.2GHZ 8 SHIELD NONE 1.0X0.5X0.5MM R/TP
MURATA MANUFACTURING CO.,LTD.
6 J8000
Socket
DIMM/SIMM
EAG63393401
C-203-0100 6P STRAIGHT STANDARD SMD
T/REEL - SHENZHEN EVERWIN PRECISION
TECHNOLOGY CO.,LTD.
6
R4022
R4024
Resistor,Chip ERHZ0000204
MCR01MZP5F1003 100KOHM 1% 1/16W 1005
R/TP - ROHM.
