13. EXPLODED VIEW & REPLACEMENT PART LIST
- 195 -
Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6
R1007
R1008
Resistor,Chip ERHZ0000517
MCR01MZP5J910 91OHM 5% 1/16W 1005 R/TP -
ROHM.
6
VA5003
VA5004
VA5006
VA6000
VA6001
Varistor SEVY0004001
EVLC18S02003 18V 0% 3F 1.0*0.5*0.6 NONE
SMD R/TP AMOTECH CO., LTD.
6 FB9001 Filter,Bead EAM62072101
BLM15PD600SN1D 60 ohm 1.0x0.5x0.5 25% 0.06
ohm 1.1A SMD R/TP 2P 0 MURATA
MANUFACTURING CO.,LTD.
6
FL5000
FL5002
FL5003
FL5004
FL5005
Filter,EMI/Power SFEY0010501
ICVE10184E150R101FR ESD/EMI 0HZ 15pF 0H
SMD R/TP INNOCHIPS TECHNOLOGY
6
R1017
R4015
Resistor,Chip ERHY0000105
MCR01MZP5F51R0 51OHM 1% 1/16W 1005 R/TP
- ROHM.
6 C5001
Capacitor
Ceramic,Chip
ECCH0007804
CL05A225MP5NSNC 2.2uF 20% 10V X5R -
55TO+85C 1005 R/TP 0.5MM - SAMSUNG
ELECTRO-MECHANICS CO., LTD.
6 U3001 IC,MCP,eMMC EAN62583101
H9DP32A4JJBCGR-KEM NAND/4G
SDRAM/4G(2G*2/ 32bit)
2.7VTO3.6V,1.65VTO1.95V,1.7VTO1.95V
11.5x13.0x1.0 TR 153P NAND+DDR SDRAM FGBA
4GB eMMC v4.41+4Gb LPDDR1 MCP (20nm 32Gb
MLC+38nm 2Gb 200MHz LPDDR1
)
HYNIX
)
SEMICONDOCTOR
6 L1030
Inductor
Multilayer,Chip
ELCH0001033
HK1005 1N5S-T 1.5NH 0.3NH - 300mA 0.1OHM
6GHZ 8 SHIELD NONE 1.0X0.5X0.5MM R/TP
TAIYO YUDEN CO.,LTD
6 D7000 Diode,Switching EDSY0011901
SDB310Q 340mV 30V 200mA 1A 0SEC 150mW
EMD2 R/TP 2P 1 AUK CORP
6
C1081
C1096
Capacitor
Ceramic,Chip
ECCH0005603
GRM188R61A225K 2.2uF 10% 10V X5R -
55TO+85C 1608 R/TP - MURATA
MANUFACTURING CO.,LTD.
6
VA7009
VA7010
Varistor SEVY0007901
ICVS0505481FR 5.6V 0% 480F 1.0*0.5*0.55 NONE
SMD R/TP INNOCHIPS TECHNOLOGY
6
R2009
R3011
R5000
Resistor,Chip ERHZ0000406
MCR01MZP5J104 100KOHM 5% 1/16W 1005 R/TP
- ROHM.
