13. EXPLODED VIEW & REPLACEMENT PART LIST
- 196 -
Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6
C9011
C9031
Capacitor
Ceramic,Chip
ECCH0009103
C0603C0G1H101JT00NN 100pF 5% 50V C0G -
55TO+125C 0603 R/TP - - TDK CORPORATION
6 FL1001 Filter,Saw,Dual EAM62692701
SFRM81KB002 850/900MHz 1.5x1.1x0.6t SMD
R/TP 10P WISOL.CO.,LTD
6
C1104
L1009
L1035
L1036
Inductor
Multilayer,Chip
ELCH0004705
1005GC2T8N2JLF 8.2NH 5% - 250mA 0.37OHM
2.8GHZ 8 SHIELD NONE 1.0X0.5X0.5MM R/TP
PILKOR ELECTRONICS LTD.
6 C7015
Capacitor
Ceramic,Chip
ECZH0001421
C1608X5R0J225KT000N 2.2uF 10% 6.3V X5R -
55TO+85C 1608 R/TP - TDK KOREA
COOPERATION
6 CN5000 Connector,BtoB ENBY0034201
GB042-24S-H10-E3000 24P 0.40MM STRAIGHT
SOCKET SMD R/TP 1M - LS Mtron Ltd.
6 U7000 IC,Comparator EAN61862901
FSA8008AUMX 2.7~4.4V 0 COMPARATOR MLP
R/TP 10P Headset Detector Differential Input
Voltage 1.6~Vdd FAIRCHILD SEMICONDUCTOR
HONG KONG LTD.
6 R1022 Resistor,Chip ERHY0000104
MCR01MZP5F49R9 49.9OHM 1% 1/16W 1005
R/TP - ROHM.
6 C4037
Capacitor
Ceramic,Chip
ECCH0000149
MCH155CN332KK 3.3nF 10% 50V X7R -
55TO+125C 1005 R/TP - ROHM Semiconductor
KOREA CORPORATION
C1005X5R1A224KT000E 220nF 10% 10V X5R
6 C9034
Capacitor
Ceramic,Chip
ECZH0001216
C1005X5R1A224KT000E 220nF 10% 10V X5R
-
55TO+85C 1005 R/TP - TDK KOREA
COOPERATION
6
C1129
L1015
Capacitor(High
Frequency),Cerami
c,Chip
EAE62883401
GRM1555C1H4R7C_H 4.7pF 0.25PF 50V C0G -
55TO+125C 1005 R/TP 0.5+/-0.05 L:1.0+-0.05
W:0.5+-0.05 T:0.5+-0.05 MURATA
MANUFACTURING CO.,LTD.
6 L1002
Inductor
Multilayer,Chip
ELCH0003844
LQG15HS2N0S02D 2NH 0.3NH - 300mA 0.1OHM
6GHZ 8 SHIELD NONE 1.0X0.5X0.5MM R/TP
MURATA MANUFACTURING CO.,LTD.
6 U1001 IC,Power Amplifier EAN62633501
SKY77584 - - - 0W 0W - 0 SMD R/TP 28P -
SKYWORKS SOLUTIONS INC.
6 C1090 Resistor,Chip ERHZ0000504
MCR01MZP5J680 68OHM 5% 1/16W 1005 R/TP -
ROHM.
