13. EXPLODED VIEW & REPLACEMENT PART LIST
- 197 -
Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6 L9003
Inductor
Multilayer,Chip
ELCH0003842
LQG15HSR10J02D 100NH 5% - 150mA - -
1.25OHM 600MHZ 8 SHIELD NONE
1.0X0.5X0.5MM R/TP MURATA
MANUFACTURING CO.,LTD.
6 D4000 Diode,TVS EDTY0012102
PESD5V0V1BL 5V 5.8V min. 12.5V 4.8A 45W
SOD-882 R/TP 2P 1 STC CORP.
6 C4030
Capacitor
Ceramic,Chip
ECCH0000117
CL05C270JB5NNNC 27pF 5% 50V NP0 -
55TO+125C 1005 R/TP 0.5 SAMSUNG ELECTRO-
MECHANICS CO., LTD.
6 C4068
Capacitor
Ceramic,Chip
ECCH0009603
CE JMK212 BJ476MG-T 47uF 20% 6.3V X5R -
55TO+85C 2012 R/TP 1.25mm - TAIYO YUDEN
CO.,LTD
6 L9008
Inductor
Multilayer,Chip
EAP62227501
LG HK 0603 5N6S-T 5.6NH 0.3NH - 260mA - -
0.36OHM 4.6GHZ 5 SHIELD - 0.6X0.3X0.3MM
R/TP TAIYO YUDEN CO.,LTD
6 C2004
Capacitor
Ceramic,Chip
ECCH0000147
MCH155CN222KK 2.2nF 10% 50V X7R -
55TO+125C 1005 R/TP - ROHM.
6 C9047
Capacitor
Ceramic,Chip
ECCH0000185
GRM1555C1H5R6C 5.6pF 0.25PF 50V NP0 -
55TO+125C 1005 R/TP - MURATA
MANUFACTURING CO.,LTD.
6 L1038
Inductor
Multilayer,Chip
ELCH0001034
HK1005 3N3S-T 3.3NH 0.3NH - 300mA 0.16OHM
6GHZ 8 SHIELD NONE 1.0X0.5X0.5MM R/TP
TAIYO YUDEN CO.,LTD
LXES11DAA2-135 COMMON MODE NOISE
FILTER 0 0000000000004F 0H SMD R/TP CM
6 FL4001 Filter,EMI/Power EAM62770201
FILTER
-
0
.
0000000000004F 0H SMD R/TP CM
impedence : 60 ohm Leakage Current : 2uA
MURATA MANUFACTURING CO.,LTD.
6
C9003
L1028
Resistor,Chip ERHZ0000401
MCR01MZSJ000 0OHM 5% 1/16W 1005 R/TP -
ROHM.
6
R9000
R9004
Resistor,Chip ERHZ0000407
MCR01MZP5J105 1MOHM 5% 1/16W 1005 R/TP -
ROHM.
6 L9011
Inductor
Multilayer,Chip
EAP62246401
LG HK 0603 22NJ-T 22NH 5% - 150mA - - 1OHM
1.8GHZ 5 SHIELD - 0.6X0.3X0.3MM R/TP TAIYO
YUDEN CO.,LTD
6 U4001 IC,PMIC EAN62090501
PM8029 3 to 4.4V adj 1.3W NSP R/TP 140P -
QUALCOMM INCORPORATED.
6 C2001
Capacitor
Ceramic,Chip
ECCH0000122
MCH155A470JK 47pF 5% 50V NP0 -55TO+125C
1005 R/TP - ROHM Semiconductor KOREA
CORPORATION
